Max (M1)
Model Max (M1)Part no. ZB555KL-4A071EUEAN 4712900984958
112 specifications Checked today
- Display14 cm (5.5")
- Resolution1440 x 720 pixels
- ProcessorSnapdragon
- Memory3 GB
- Storage32 GB
- Camera13 MP
Overview
- Display
- 14 cm (5.5")
- Resolution
- 1440 x 720 pixels
- Processor
- Snapdragon
- Memory
- 3 GB
- Storage
- 32 GB
- Camera
- 13 MP
- Brand
- ASUS
- Category
- Phone
- Model
- Max (M1)
- Part numbers
- ZB555KL-4A071EU, ZB555KL-4G074EU
- EAN / UPC
- 4712900984958, 4712900985016
- Also known as
- ASUS ZenFone Max (M1) 14 cm (5.5") Dual SIM Android 8.0 4G Micro-USB 3 GB 32 GB 4000 mAh Black
Specifications
112 specifications in 19 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 14 cm (5.5") |
| Display resolution | 1440 x 720 pixels |
| Screen shape | Flat |
| Panel type | IPS |
| Display number of colours | 16 million colours |
| Native aspect ratio | 18:9 |
| Touch technology | Multi-touch |
| Pixel density | 245 ppi |
| Touchscreen type | Capacitive |
Processor
| Specification | Value |
|---|---|
| Processor family | Snapdragon |
| Processor cores | 4 |
Storage
| Specification | Value |
|---|---|
| RAM capacity | 3 GB |
| Internal storage capacity | 32 GB |
| RAM type | LPDDR3 |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Memory card slot type | Dedicated slot |
| USB mass storage | Yes |
Camera
| Specification | Value |
|---|---|
| Rear camera type | Dual camera |
| Rear camera resolution (numeric) | 13 MP |
| Second rear camera resolution (numeric) | 8 MP |
| Rear camera aperture number | 2 |
| Second rear camera field of view (FOV) angle | 120° |
| Front camera type | Single camera |
| Front camera resolution (numeric) | 8 MP |
| Front camera aperture number | 2.2 |
| Rear camera flash | Yes |
| Flash type | LED |
| Maximum frame rate | 30 fps |
| Resolution at capture speed | 1920x1080@30fps |
| Video recording modes | 1080p |
| Auto focus | Yes |
| Zoom capability | Yes |
| Video recording | Yes |
| Time lapse mode | Yes |
| Geotagging | Yes |
Network
| Specification | Value |
|---|---|
| SIM card capability | Dual SIM |
| Mobile network generation | 4G |
| SIM card type | NanoSIM |
| 2G standards | GSM |
| 3G standards | UMTS, WCDMA |
| 4G standard | LTE |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| 2G bands (primary SIM) | 800,850,1800,1900 MHz |
| 2G bands (secondary SIM) | 850,900,1800,1900 MHz |
| Tethering (modem-mode) | Yes |
| Wi-Fi Direct | Yes |
Subscription
| Specification | Value |
|---|---|
| Subscription type | No subscription |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB connector type | Micro-USB |
| Headphone connectivity | 3.5 mm |
Messaging
| Specification | Value |
|---|---|
| Short Message Service (SMS) | Yes |
| Multimedia Messaging Service (MMS) | Yes |
| Instant messaging (IM) | Yes |
| Chat | Yes |
| Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Bar |
| Product colour | Black |
| Colour name | Deepsea Black |
Performance
| Specification | Value |
|---|---|
| Video call | Yes |
| Fast charging | Yes |
| Wireless charging | No |
| Fingerprint reader | Yes |
| Flight mode | Yes |
| Microphone mute | Yes |
| Personal info management (PIM) | Alarm clock, Calculator, Calendar |
| Personalization | Icons, Menu, Shortcuts |
| Speakerphone | Yes |
| Support for contact groups | Yes |
| Themes | Wallpapers |
| Voice dialling | Yes |
| Vibrating alert | Yes |
Multimedia
| Specification | Value |
|---|---|
| FM radio | Yes |
Call management
| Specification | Value |
|---|---|
| Call divert | Yes |
| Call hold | Yes |
| Call timer | Yes |
| Call waiting | Yes |
| Caller ID | Yes |
| Conference call | Yes |
| Speed dialling | Yes |
Software
| Specification | Value |
|---|---|
| Platform | Android |
| Operating system installed | Android 8.0 |
| App distribution platform | Google Play |
Battery
| Specification | Value |
|---|---|
| Battery capacity | 4000 mAh |
| Talk time (3G) (max) | 36 h |
| Standby time (4G) (max) | 984 h |
| Browsing time (Wi-Fi) (max) | 23 h |
| Continuous video playback time (max) | 16 h |
Sensors
| Specification | Value |
|---|---|
| Accelerometer | Yes |
| Ambient light sensor | Yes |
| Proximity sensor | Yes |
| Gyroscope | Yes |
| Orientation sensor | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 150 g |
| Width | 70.9 mm |
| Depth | 8.7 mm |
| Height | 147.3 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
| Cables included | USB |
| SIM card ejector pin | Yes |
Other features
| Specification | Value |
|---|---|
| Touchscreen | Yes |
