NV7B7970CDA 76 L Beige
Model NV7B7970CDAPart no. NV7B7970CDA/U1EAN 8806094679694
64 specifications
- Display10.9 cm (4.3")
- Energy classA+
- Weight47 kg
- ColourBeige
- Number of ovens1
- Appliance placementBuilt-in
Overview
- Display
- 10.9 cm (4.3")
- Energy class
- A+
- Weight
- 47 kg
- Colour
- Beige
- Number of ovens
- 1
- Appliance placement
- Built-in
- Brand
- Samsung
- Category
- Oven
- Model
- NV7B7970CDA
- Part number
- NV7B7970CDA/U1
- EAN / UPC
- 8806094679694
- Also known as
- Samsung NV7B7970CDA 76 L Beige
Specifications
64 specifications in 9 groups
Oven
| Specification | Value |
|---|---|
| Number of ovens | 1 |
| Oven size | Large |
| Oven type | Electric |
| Oven cooking method | Combi steam |
| Total oven(s) interior capacity | 76 L |
| Oven net capacity | 76 L |
| Top heating power | 1600 W |
| Bottom heating power | 1100 W |
| Oven thermostat range | 30 - 300 °C |
| Grill | Yes |
| Convection cooking | Yes |
| Steam cooking | Yes |
| Conventional cooking | Yes |
| Self-cleaning | Yes |
| Cleaning type | Pyrolytic + Steam |
Design
| Specification | Value |
|---|---|
| Appliance placement | Built-in |
| Product colour | Beige |
| Interior material | Enamelled ceramic |
| Control type | Rotary, Touch |
| Built-in display | Yes |
| Display type | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Door hinge | Down |
| Number of glass door panels | 4 |
| Automatic door opening | Yes |
| Soft closing door | No |
Ergonomics
| Specification | Value |
|---|---|
| Integrated clock | Yes |
| Wi-Fi controlled | Yes |
| Apps supported | Samsung SmartThings |
| Food probe | Yes |
| Food probe type | Wired |
| Child lock | Yes |
Power
| Specification | Value |
|---|---|
| Energy efficiency scale | A+++ to D |
| Connected load | 3950 W |
| AC input voltage | 230 - 240 V |
| AC input frequency | 50 Hz |
| Energy efficiency index (EEI) | 81.6 |
| Power connection type | Power plug |
| Energy consumption (conventional) | 1.05 kWh |
| Energy consumption (forced convection) | 0.71 kWh |
| Energy efficiency class (legacy scale) | A+ |
Lighting
| Specification | Value |
|---|---|
| Interior light | Yes |
| Lamp type | Halogen |
| Illumination location | Side, Top |
| Bulb power | 25 W |
| Bulb power 2 | 40 W |
Brand-specific features
| Specification | Value |
|---|---|
| Samsung technologies (cooking) | WiFi cooking, Air fry function, Meat probe, SmartThings, Steam cleaning, Telescopic Rail, Dual Cook Flex™ |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 595 mm |
| Depth | 570 mm |
| Height | 596 mm |
| Weight | 47 kg |
| Interior dimensions (W x D x H) | 560 x 549 x 579 mm |
| Installation compartment width (min) | 56 cm |
| Installation compartment depth | 55 cm |
| Installation compartment height | 60 cm |
| Installation compartment height (min) | 59 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 694 mm |
| Package depth | 660 mm |
| Package height | 660 mm |
| Package weight | 52 kg |
Packaging content
| Specification | Value |
|---|---|
| Glass pan included | Yes |
| Grill grid included | Yes |
| Meat probe included | Yes |
| Telescopic rail included | Yes |
