Seagate DS-7716NI-K4/16P 1.5U Black

Seagate DS-7716NI-K4/16P 1.5U Black

Model DS-7716NI-K4/16PPart no. 303603710 + 4X ST4000VX007

42 specifications
  • Weight5 kg
  • ColourBlack
  • Video input channels16 channels
  • Wi-FiNo
  • Number of HDDs installed4
  • Ethernet LAN (RJ-45) ports9
See all specifications

Overview

Weight
5 kg
Colour
Black
Video input channels
16 channels
Wi-Fi
No
Number of HDDs installed
4
Ethernet LAN (RJ-45) ports
9
Brand
Seagate
Model
DS-7716NI-K4/16P
Part numbers
303603710 + 4X ST4000VX007, 303603710 + 4X ST6000VX0023
Also known as
Seagate DS-7716NI-K4/16P 1.5U Black

Specifications

42 specifications in 10 groups

Performance

Video input channels16 channels
Alarm input channels16
Alarm output channels4
Maximum resolution3840 x 2160 pixels
Supported resolutions3840 × 2160, 2560 × 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Video formats supportedH.264, H.265, MPEG4

Wireless LAN features

Wi-FiNo

Hard drive

Number of HDDs installed4
Number of HDDs supported4
Maximum storage capacity6 TB
HDD interfaceSerial ATA

Ports & interfaces

Ethernet LAN (RJ-45) ports9
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity8
HDMI outputYes
HDMI ports quantity1
USB 2.0 ports quantity1
VGA (D-Sub) output ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Audio RCA inputs1
Audio RCA outputs1
RS-232 interfaceYes
RS-485 ports1
Networking standardsIEEE 802.3af, IEEE 802.3at
Supported network protocolsTCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Features

Rack mountingYes
Rack capacity1.5U
On/off switchYes
Product colourBlack

Display

Supported graphics resolutions1024 × 768, 1280 × 1024, 1920 × 1080

Power

Power consumption (max)300 W
Power consumption (typical)20 W
AC input voltage100 - 240 V
Total Power over Ethernet (PoE) budget200 W

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width445 mm
Depth390 mm
Height70 mm
Weight5 kg

Packaging content

Quick installation guideYes
