QNAP VS-4116 PRO+

VS-4116 PRO+

Model VS-4116 PRO+Part no. VS-4116-PRO+EAN 5711045970634

45 specifications

Memory4000 MB
Storage0 GB
Power250 W
Weight4.6 kg
ColourBlack
Video input channels16 channels

See all specifications

Overview

Memory: 4000 MB
Storage: 0 GB
Power: 250 W
Weight: 4.6 kg
Colour: Black
Video input channels: 16 channels

Brand: QNAP
Category: Network Video Recorders (NVR)
Model: VS-4116 PRO+
Part numbers: VS-4116-PRO+, VS-4116-PRO+-EU, VS-4116PRO+
EAN / UPC: 5711045970634, 4712511123876, 4053162675346
Also known as: QNAP VS-4116 PRO+ Black

Specifications

45 specifications in 10 groups

Performance

Specification	Value
Video input channels	16 channels
Maximum resolution	1920 x 1080 pixels
Internal memory	4000 MB
Internal memory type	DDR3
Video formats supported	H.264, MPEG4, MxPEG
Backup function	Yes
Maximum frame rate	30 fps
Number of fans	1 fan(s)
PTZ control	Yes
Throughput data rate	250 Mbit/s

Hard drive

Specification	Value
Number of HDDs installed	0
HDD capacity	0 GB
Number of HDDs supported	4
Total installed storage capacity	0 GB
Maximum storage capacity	24 TB
HDD interface	Serial ATA II, Serial ATA III
RAID support	Yes
RAID levels	1, 5+HS, 5, 6

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
Ethernet LAN data rates	1000 Mbit/s
HDMI output	Yes
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Supported network protocols	HTTP, TCP/IP, SMTP, DHCP, Static IP, DNS, DDNS, FTP, NTP, UPnP

Features

Specification	Value
Rack mounting	No
LED indicators	HDD, LAN, Status, USB
On/off switch	Yes
Product colour	Black
Reset button	Yes
Certification	CE, FCC, VCCI, BSMI

Processor

Specification	Value
Built-in processor	Yes
Processor frequency	2.6 GHz

Power

Specification	Value
Power consumption (typical)	62.7 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power	250 W

System requirements

Specification	Value
Linux operating systems supported	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	180 mm
Depth	235 mm
Height	185 mm
Weight	4.6 kg
Package weight	5.9 kg

Packaging content

Specification	Value
Cables included	AC, LAN (RJ-45)
