LevelOne HUBBLE 9-Channel Network Video Recorder
LevelOne

HUBBLE 9-Channel Network Video Recorder

Model NVR-1209EAN 846359034514

57 specifications
  • Storage0 GB
  • OSEmbedded LINUX
  • Weight1.39 kg
  • ColourBlack
  • Video input channels9 channels
  • Wi-FiNo
See all specifications

Overview

Storage
0 GB
OS
Embedded LINUX
Weight
1.39 kg
Colour
Black
Video input channels
9 channels
Wi-Fi
No
Brand
LevelOne
Model
NVR-1209
Part number
NVR-1209
EAN / UPC
846359034514, 4015867190760
Also known as
LevelOne HUBBLE 9-Channel Network Video Recorder

Specifications

57 specifications in 11 groups

Performance

Video input channels9 channels
Number of users3 user(s)
Video motion detectionYes
Video loss detectionYes
Audio formats supportedG.711, PCM
Video formats supportedH.264
Operating system installedEmbedded LINUX
Languages supportMulti
Maximum frame rate30 fps
Number of simultaneous viewers3
PTZ controlYes
Playback modesForward, Pause, Reverse, Stop
SnapshotYes
Throughput data rate36 Mbit/s

Wireless LAN features

Wi-FiNo

Hard drive

Number of HDDs installed0
HDD capacity0 GB
Number of HDDs supported2
Total installed storage capacity0 GB
Maximum storage capacity8 TB
HDD interfaceSerial ATA
HDD size3.5"

Ports & interfaces

Ethernet LAN (RJ-45) ports2
HDMI outputYes
USB 2.0 ports quantity2
DC-in jackYes

Features

LED indicatorsYes
Product colourBlack
Country of originTaiwan
CertificationCE, FCC, UL

Power

Power consumption (typical)22 W
Output voltage12 V

System requirements

Windows operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
Browser supportedMicrosoft Internet Explorer 9/10/11
Minimum processorIntel Core 2 Quad
Minimum processor speed2.66 GHz
Minimum RAM4 GB

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 85%

Weight & dimensions

Width135 mm
Depth245 mm
Height115 mm
Weight1.39 kg
Package width380 mm
Package depth195 mm
Package height170 mm
Package typeBox
Package weight980 g

Packaging content

CD manualYes
Cables includedAC
Quick installation guideYes

Logistics data

Master (outer) case width410 mm
Master (outer) case length295 mm
Master (outer) case height380 mm
Master (outer) case gross weight10.6 kg
Products per master (outer) case4 pc(s)
