GEMINI 64-Channel Network Video Recorder, RAID, H.265, HDMI, VGA
Model NVR-0764EAN 4015867206416
57 specifications
- Storage0 GB
- OSEmbedded LINUX
- Weight10 kg
- ColourBlack
- Video input channels64 channels
- Wi-FiNo
Overview
- Storage
- 0 GB
- OS
- Embedded LINUX
- Weight
- 10 kg
- Colour
- Black
- Video input channels
- 64 channels
- Wi-Fi
- No
- Brand
- LevelOne
- Category
- Network Video Recorders (NVR)
- Model
- NVR-0764
- Part number
- NVR-0764
- EAN / UPC
- 4015867206416, 4015867236697
- Also known as
- LevelOne GEMINI 64-Channel Network Video Recorder, RAID, H.265, HDMI, VGA
Specifications
57 specifications in 11 groups
Performance
| Specification | Value |
|---|---|
| Video input channels | 64 channels |
| Alarm input channels | 4 |
| Alarm output channels | 16 |
| Video recording modes | 720p, 1080p |
| Maximum resolution | 3840 x 2160 pixels |
| Number of users | 128 user(s) |
| On Screen Display (OSD) | Yes |
| Video formats supported | H.264, H.264+, H.265, MPEG4 |
| Operating system installed | Embedded LINUX |
| Input bandwidth | 320 Mbit/s |
| Output bandwidth | 256 Mbit/s |
| PTZ control | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | No |
Hard drive
| Specification | Value |
|---|---|
| Number of HDDs installed | 0 |
| HDD capacity | 0 GB |
| Number of HDDs supported | 8 |
| Maximum storage capacity | 80 TB |
| HDD size | 3.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio RCA outputs | 2 |
| Line-in | Yes |
| RS-232 interface | Yes |
| RS-485 ports | 1 |
| eSATA | Yes |
| Supported network protocols | TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP,RTSP, SNMP, FTP |
Features
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| LED indicators | Power |
| On/off switch | Yes |
| Product colour | Black |
| Certification | CE,FCC,UL |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 200 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 470 mm |
| Depth | 90 mm |
| Height | 445 mm |
| Weight | 10 kg |
| Package width | 510 mm |
| Package depth | 110 mm |
| Package height | 450 mm |
| Package type | Box |
| Package weight | 12 kg |
Packaging content
| Specification | Value |
|---|---|
| CD manual | Yes |
| Cables included | AC |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 520 mm |
| Master (outer) case length | 180 mm |
| Master (outer) case height | 510 mm |
| Master (outer) case gross weight | 12.7 kg |
| Products per master (outer) case | 1 pc(s) |
