Pro NVR5864-4KS2 network video recorder 1.5U Black
Dahua Technology

Pro NVR5864-4KS2 network video recorder 1.5U Black

Model NVR5864-4KS2

65 specifications
  • OSEmbedded LINUX
  • Weight4.65 kg
  • ColourBlack
  • Video input channels16 channels
  • Number of HDDs supported4
  • Ethernet LAN (RJ-45) ports1
See all specifications

Overview

OS
Embedded LINUX
Weight
4.65 kg
Colour
Black
Video input channels
16 channels
Number of HDDs supported
4
Ethernet LAN (RJ-45) ports
1
Brand
Dahua Technology
Model
NVR5864-4KS2
Part number
NVR5864-4KS2
Also known as
Dahua Technology Pro NVR5864-4KS2 network video recorder 1.5U Black

Specifications

65 specifications in 9 groups

Performance

Video input channels16 channels
Alarm input channels16
Alarm output channels6
Maximum resolution3840 x 2160 pixels
Supported resolutions3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Bit rate20000 Kbit/s
Number of users128 user(s)
Two-way talkYes
Video motion detectionYes
Number of motion detection zones396
Video loss detectionYes
Multi-screenYes
On Screen Display (OSD)Yes
Video formats supportedH.264, H.265, M-JPEG, MPEG4
Operating system installedEmbedded LINUX
Backup functionYes
PTZ controlYes
Playback controlsYes
Playback modesBackup selection, Digital zoom, Forward, Full screen, Next camera, Pause, Play, Previous camera, Repeat, Reverse, Shuffle, Speed Adjust, Stop
SnapshotYes
Throughput data rate320 Mbit/s
Recording modesManual, Schedule, Stop
Recording time120 min
Face detectionYes

Hard drive

Number of HDDs supported4
Maximum storage capacity32 TB
HDD interfaceSerial ATA III

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity16
HDMI outputYes
HDMI ports quantity2
USB 2.0 ports quantity1
VGA (D-Sub) output ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Audio RCA inputs1
Audio RCA outputs1
eSATA ports quantity1
SATA revision3.0
Internal SATA ports quantity4
RS-232 interfaceYes
RS-485 ports1
Networking standardsIEEE 802.3af, IEEE 802.3at
Supported network protocolsHTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search

Features

Rack mountingYes
Rack capacity1.5U
Brand compatibilityAny brand
Compatible productsDahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec
Product colourBlack
CertificationCE, FCC, UL, EN55022, EN55024, EN50130-4, EN60950-1, Part15 subpartB,ANSI C63.4-2014, UL60950-1+CAN/CSA C22.2 No.60950-1

Processor

Built-in processorYes
Processor cores4

Power

Power consumption (typical)17.5 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

System requirements

Mobile operating systems supportedAndroid, iOS

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Storage temperature (T-T)-20 - 70 °C
Storage relative humidity (H-H)0 - 90%

Weight & dimensions

Width440 mm
Depth411.1 mm
Height94.9 mm
Weight4.65 kg
Package weight7 kg
