Dahua Technology WizSense NVR5216-16P-AI/ANZ 1U Black
Dahua Technology

WizSense NVR5216-16P-AI/ANZ 1U Black

Model NVR5216-16P-AI/ANZPart no. DHI-NVR5216-16P-AI/ANZ

50 specifications
  • OSEmbedded LINUX
  • Weight2.66 kg
  • ColourBlack
  • Video input channels16 channels
  • Number of HDDs supported2
  • Ethernet LAN (RJ-45) ports1
See all specifications

Overview

OS
Embedded LINUX
Weight
2.66 kg
Colour
Black
Video input channels
16 channels
Number of HDDs supported
2
Ethernet LAN (RJ-45) ports
1
Brand
Dahua Technology
Model
NVR5216-16P-AI/ANZ
Part number
DHI-NVR5216-16P-AI/ANZ
Also known as
Dahua Technology WizSense NVR5216-16P-AI/ANZ 1U Black

Specifications

50 specifications in 8 groups

Performance

Video input channels16 channels
Alarm input channels4
Alarm output channels2
Video recording modes720p, 1080p
Supported resolutions32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Video motion detectionYes
Audio formats supportedG.711 A-law, G.711 μ-law, G.726, PCM
Video formats supportedH.264, H.264+, H.265, H.265+, M-JPEG
Operating system installedEmbedded LINUX
Input bandwidth384 Mbit/s
Maximum frame rate30 fps
Output bandwidth384 Mbit/s
Face detectionYes

Hard drive

Number of HDDs supported2
Maximum storage capacity16 TB
HDD interfaceSATA

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity16
HDMI ports quantity1
USB 2.0 ports quantity1
VGA (D-Sub) output ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Audio RCA inputs1
Audio RCA outputs1
RS-232 interfaceYes
RS-232 ports1
RS-485 ports1
Supported network protocolsHTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration

Features

Rack mountingYes
Rack capacity1U
Product colourBlack
CertificationFCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3:2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 CE-LVD: EN 62368-1: 2014

Processor

Built-in processorYes

Power

AC input voltage100 - 240 V
AC input frequency47 - 63 Hz
Power over Ethernet (PoE) power per port25.5 W
Total Power over Ethernet (PoE) budget130 W

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 93%
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Width375 mm
Depth329.3 mm
Height53 mm
Weight2.66 kg
Package width449 mm
Package depth170 mm
Package height421 mm
Package weight3.82 kg
