Dahua Technology WizSense NVR4416-4KS2/I 1.5U
Dahua Technology

WizSense NVR4416-4KS2/I 1.5U

Model NVR4416-4KS2/IPart no. DHI-NVR4416-4KS2/I

58 specifications
  • OSEmbedded LINUX
  • Weight4.25 kg
  • Video input channels16 channels
  • Wi-FiNo
  • Number of HDDs supported4
  • Ethernet LAN (RJ-45) ports2
See all specifications

Overview

OS
Embedded LINUX
Weight
4.25 kg
Video input channels
16 channels
Wi-Fi
No
Number of HDDs supported
4
Ethernet LAN (RJ-45) ports
2
Brand
Dahua Technology
Model
NVR4416-4KS2/I
Part number
DHI-NVR4416-4KS2/I
Also known as
Dahua Technology WizSense NVR4416-4KS2/I 1.5U

Specifications

58 specifications in 11 groups

Performance

Video input channels16 channels
Alarm input channels16
Alarm output channels4
People countingYes
Video motion detectionYes
Multi-screenYes
Audio formats supportedG.726, PCM
Video formats supportedH.264, H.265, M-JPEG
Operating system installedEmbedded LINUX
Backup functionYes
Input bandwidth256 Mbit/s
Maximum frame rate30 fps
Output bandwidth160 Mbit/s
SnapshotYes
Face detectionYes

Wireless LAN features

Wi-FiNo

Hard drive

Number of HDDs supported4
Maximum storage capacity10 TB
HDD interfaceSATA III
RAID supportYes

Ports & interfaces

Ethernet LAN (RJ-45) ports2
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)No
HDMI outputYes
HDMI ports quantity1
USB 2.0 ports quantity1
VGA (D-Sub) output ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Audio RCA inputs1
Audio RCA outputs1
SATA revision3.0
Internal SATA ports quantity4
RS-232 interfaceYes
RS-232 ports1
RS-485 ports1
Supported network protocolsHTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P

Features

Rack mountingYes
Rack capacity1.5U
CertificationFCC:47 CFR FCC Part15,SubpartB,Class A CE-EMC:EN 55032:2015,Class A;EN IEC 61000-3-2:2019;EN 61000-3-3:2013+A1:2019;EN 55024:2010+A1:2015;EN 55035:2017;EN 50130-4:2011+A1:2014 CE-LVD:EN 62368-1:2014+A11:2017

Processor

Built-in processorYes

Display

Built-in displayYes

Power

Power consumption (typical)8 W
AC input voltage100-240 V
AC input frequency50 - 60 Hz

System requirements

Browser supportedChrome, PCAPP, IE9 or higher, Firefox

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 93%
Storage temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)30 - 85%

Weight & dimensions

Width440 mm
Depth415.6 mm
Height76 mm
Weight4.25 kg
Package width529 mm
Package depth499 mm
Package height211 mm
Package typeBox
Package weight6.48 kg
