Dahua Technology WizSense NVR2104HS-I Black

Dahua Technology

WizSense NVR2104HS-I Black

Model NVR2104HS-IPart no. DH-NVR2104HS-I

43 specifications

OSEmbedded LINUX
Weight810 g
ColourBlack
Video input channels4 channels
Number of HDDs installed1
Built-in processorYes

See all specifications

Overview

OS: Embedded LINUX
Weight: 810 g
Colour: Black
Video input channels: 4 channels
Number of HDDs installed: 1
Built-in processor: Yes

Brand: Dahua Technology
Category: Network Video Recorders (NVR)
Model: NVR2104HS-I
Part number: DH-NVR2104HS-I
Also known as: Dahua Technology WizSense NVR2104HS-I Black

Specifications

43 specifications in 10 groups

Performance

Specification	Value
Video input channels	4 channels
Video recording modes	1080p
Maximum resolution	3840 x 2160 pixels
Audio formats supported	AAC, G.711 A-law, G.711 μ-law, PCM
Video formats supported	H.264, H.264+, H.265, H.265+, MJPG
Operating system installed	Embedded LINUX
Backup function	Yes
Input bandwidth	60 Mbit/s
Output bandwidth	80 Mbit/s
Playback modes	Backup selection, Forward, Frame by Frame, Full screen, Pause, Play, Stop
Recording modes	Manual

Hard drive

Specification	Value
Number of HDDs installed	1
Maximum storage capacity	8 TB
HDD interface	SATA

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Audio RCA inputs	1
Audio RCA outputs	1
Internal SATA ports quantity	1
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS

Features

Specification	Value
Product colour	Black
Certification	CE/FCC

Processor

Specification	Value
Built-in processor	Yes

Power

Specification	Value
Power consumption (typical)	10 W
Output current	1.5 A
Output voltage	12 V

System requirements

Specification	Value
Mobile operating systems supported	Android, iOS
Browser supported	Chrome, IE9 or above, Firefox

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 93%
Storage temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 85%

Weight & dimensions

Specification	Value
Width	260 mm
Depth	232.7 mm
Height	47.6 mm
Weight	810 g
Package width	89 mm
Package depth	333 mm
Package height	315 mm
Package weight	1.38 kg

Packaging content

Specification	Value
Quick installation guide	Yes
