Dahua Technology WizSense NVR2104-P-I2 network video recorder 1U Black
Dahua Technology

WizSense NVR2104-P-I2 network video recorder 1U Black

Model NVR2104-P-I2EAN 6923172520098

49 specifications
  • OSEmbedded LINUX
  • Weight500 g
  • ColourBlack
  • Video input channels4 channels
  • Number of HDDs installed1
  • Rack capacity1U
See all specifications

Overview

OS
Embedded LINUX
Weight
500 g
Colour
Black
Video input channels
4 channels
Number of HDDs installed
1
Rack capacity
1U
Brand
Dahua Technology
Model
NVR2104-P-I2
Part number
NVR2104-P-I2
EAN / UPC
6923172520098
Also known as
Dahua Technology WizSense NVR2104-P-I2 network video recorder 1U Black

Specifications

49 specifications in 9 groups

Performance

Video input channels4 channels
Video recording modes1080p
Maximum resolution1920 x 1080 pixels
Multi-screenYes
Audio formats supportedG.711 A-law, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+
Operating system installedEmbedded LINUX
Backup functionYes
Input bandwidth80 Mbit/s
Maximum frame rate30 fps
Output bandwidth60 Mbit/s
Playback modesPause, Play, Stop
Recording modesManual

Hard drive

Number of HDDs installed1
Maximum storage capacity10 TB
HDD interfaceSATA

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity4
HDMI outputYes
HDMI ports quantity1
USB 2.0 ports quantity2
VGA (D-Sub) output ports1
Audio RCA inputs1
Audio RCA outputs1
DC-in jackYes
Supported network protocolsHTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P;Auto Registration

Features

Rack capacity1U
LED indicatorsYes
Product colourBlack
CertificationFCC:47 CFR FCC Part15,SubpartB,Class A CE-EMC:EN 55032:2015,Class A;EN IEC 61000- 3-2:2019;EN 61000-3-3:2013+A1:2019;EN 55024:2010+A1:2015;EN 55035:2017;EN 50130- 4:2011+A1:2014 CE-LVD:EN 62368-1:2014+A11:2017

Processor

Built-in processorYes

Power

Output current1.13 A
Output voltage53 V

System requirements

Mobile operating systems supportedAndroid, iOS
Browser supportedChrome; IE9 or later; Firefox

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)0 - 40%
Storage temperature (T-T)10 - 93 °C
Storage relative humidity (H-H)30 - 85%

Weight & dimensions

Width204.6 mm
Depth206.4 mm
Height45.6 mm
Weight500 g
Package width96 mm
Package depth364 mm
Package height261 mm
Package weight1.43 kg
