Dahua Technology Pro DHI-NVR4104HS-P-4KS2/L network video recorder 1U Black

Dahua Technology Pro DHI-NVR4104HS-P-4KS2/L network video recorder 1U Black

Model DHI-NVR4104HS-P-4KS2/LEAN 6939554981531

56 specifications
  • OSEmbedded LINUX
  • Weight800 g
  • ColourBlack
  • Video input channels4 channels
  • Number of HDDs supported1
  • Rack mountingYes
See all specifications

Overview

OS
Embedded LINUX
Weight
800 g
Colour
Black
Video input channels
4 channels
Number of HDDs supported
1
Rack mounting
Yes
Brand
Dahua Technology
Model
DHI-NVR4104HS-P-4KS2/L
Part number
DHI-NVR4104HS-P-4KS2/L
EAN / UPC
6939554981531
Also known as
Dahua Technology Pro DHI-NVR4104HS-P-4KS2/L network video recorder 1U Black

Specifications

56 specifications in 8 groups

Performance

Video input channels4 channels
Maximum resolution3840 x 2160 pixels
Supported resolutions3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
Bit rate20000 Kbit/s
Number of users128 user(s)
Two-way talkYes
People countingYes
Video motion detectionYes
Number of motion detection zones396
Video loss detectionYes
Multi-screenYes
On Screen Display (OSD)Yes
Video formats supportedH.264, H.265
Operating system installedEmbedded LINUX
Backup functionYes
PTZ controlYes
Recording modesContinuous, Manual, Schedule, Stop
Recording time120 min

Hard drive

Number of HDDs supported1
Maximum storage capacity6 TB
HDD interfaceSATA III

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity4
HDMI outputYes
HDMI ports quantity1
USB 2.0 ports quantity2
VGA (D-Sub) output ports1
Audio RCA inputs1
Audio RCA outputs1
SATA revision3.0
Internal SATA ports quantity1
Networking standardsIEEE 802.3af, IEEE 802.3at
Supported network protocolsHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP

Features

Rack mountingYes
Rack capacity1U
Brand compatibilityAny brand
Compatible productsDahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec
Product colourBlack
CertificationCE, FCC, UL, EN55032, EN55024, EN50130-4, EN60950-1, Part 15 Subpart B, ANSI C63.4-2014, UL60950-1+CAN/CSA C22.2 No.60950-1

Processor

Built-in processorYes
Processor cores4

Power

Power consumption (typical)7.5 W
Output current1.5 A
Output voltage48 V
Power over Ethernet (PoE) power per port25.5 W
Total Power over Ethernet (PoE) budget50 W

Operational conditions

Operating temperature (T-T)-10 - 55 °C
Storage temperature (T-T)-20 - 70 °C
Storage relative humidity (H-H)0 - 90%

Weight & dimensions

Width260 mm
Depth224.9 mm
Height47.6 mm
Weight800 g
Package weight1.6 kg
