14-Slot Media Converter Chassis
Model TL-FC1420Part no. FC1420EAN 840030702167
21 specifications
- ColourBlack
- Rack capacity2U
- Operating relative humidity (H-H)10 - 90%
- AC input frequency50 - 60 Hz
- Depth309 mm
Overview
- Colour
- Black
- Rack capacity
- 2U
- Operating relative humidity (H-H)
- 10 - 90%
- AC input frequency
- 50 - 60 Hz
- Depth
- 309 mm
- Brand
- TP-Link
- Category
- Network Equipment Chassis
- Model
- TL-FC1420
- Part number
- FC1420
- EAN / UPC
- 840030702167, 6935364010454, 6935364010461
- Also known as
- TP-Link 14-Slot Media Converter Chassis
Specifications
21 specifications in 5 groups
Technical details
| Specification | Value |
|---|---|
| Rack capacity | 2U |
| Rack mounting | Yes |
| Dimensions (WxDxH) | 482 x 309 x 86 mm |
| Number of fans | 2 fan(s) |
| Product colour | Black |
| Size (imperial) | 48.3 cm (19") |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Power
| Specification | Value |
|---|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Output current | 0.6 A |
| Output voltage | 5 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 309 mm |
| Height | 86 mm |
| Width | 482 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 455 mm |
| Package depth | 585 mm |
| Package height | 170 mm |
| Package weight | 5.98 kg |
