PowerEdge VRTX
Model PowerEdge VRTXPart no. VRTX-8998EAN 5397063768998
52 specifications
- Weight31.7 kg
- ColourBlack
- Chassis typeTower
- Storage drives installedYes
- Optical drive typeDVD+RW
- Ethernet interface typeGigabit Ethernet
Overview
- Weight
- 31.7 kg
- Colour
- Black
- Chassis type
- Tower
- Storage drives installed
- Yes
- Optical drive type
- DVD+RW
- Ethernet interface type
- Gigabit Ethernet
- Brand
- Dell
- Category
- Modular Server Chassis
- Model
- PowerEdge VRTX
- Part number
- VRTX-8998
- EAN / UPC
- 5397063768998
- Also known as
- DELL PowerEdge VRTX Tower 900 GB
Specifications
52 specifications in 11 groups
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Device class | Large Enterprise Business |
| Product colour | Black |
| Built-in display | Yes |
| Display type | LCD |
| Number of fans | 6 fan(s) |
| Redundant fans support | Yes |
| Rack rails | Yes |
| Compatible products | PowerEdge M620 PowerEdge M520 |
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 3 |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive capacity | 300 GB |
| Total installed storage capacity | 900 GB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 25 |
| Maximum supported storage capacity | 96 TB |
| HDD speed | 10000 RPM |
| Storage drive size | 2.5" |
| Hot-Plug support | Yes |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| Data transfer rate | 6 Gbit/s |
Optical drive
| Specification | Value |
|---|---|
| Optical drive type | DVD+RW |
| Optical drive interface | SATA |
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Cabling technology | 10/100/1000Base-T(X) |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 8 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots quantity | 8 |
Security
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Secure boot | Yes |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | RedHat EL Linux |
| Server operating systems supported | SUSE Linux Enterprise Server, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016, Windows Server 2016 x64 |
| Other operating systems supported | VMware vSphere ESXi |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100-240 V |
| Number of power supply units | 4 |
| Number of main power supplies | 2 |
| Power supply unit (PSU) capacity | 1600 W |
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies installed | 2 |
| 80 PLUS certification | 80 PLUS Platinum |
| Power auto-sensing | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 310 mm |
| Depth | 730 mm |
| Height | 484 mm |
| Weight | 31.7 kg |
