Designjet T7100 large format printer Colour
2400 x 1200 DPI Ethernet LAN
Model T7100Part no. CQ105A#B19#*KITEAN 8856314311842
50 specifications
- Memory32768 MB
- Storage160 GB
- Weight187 kg
- ColourYes
- Maximum roll length91 m
- Power consumption (standby)100 W
Overview
- Memory
- 32768 MB
- Storage
- 160 GB
- Weight
- 187 kg
- Colour
- Yes
- Maximum roll length
- 91 m
- Power consumption (standby)
- 100 W
- Brand
- HP
- Category
- Large Format Printer
- Model
- T7100
- Part numbers
- CQ105A#B19#*KIT, CQ105A
- EAN / UPC
- 8856314311842, 885631431153, 885631431160, 885631431177 +3 more
- Also known as
- HP Designjet T7100 large format printer Colour 2400 x 1200 DPI Ethernet LAN
Specifications
50 specifications in 11 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 6 |
| Page description languages | HP-GL/2, HP-RTL |
| Printing colours | Cyan, Dark Grey, Grey, Magenta, Matte black, Yellow |
| Print cartridge volume (metric) | 775 ml (matte black), 400 ml (matte black, cyan, magenta, yellow, gray, dark gray) |
| Print speed (normal quality) | 123.3 m²/h |
| Print head nozzles | 2112 |
| Print speed colour line drawing (draft, A1 plain paper) | 163 A1 |
| Print time black and white line drawing (draft, metric A1 plain paper) | 165 A1 |
Paper handling
| Specification | Value |
|---|---|
| Maximum roll length | 91 m |
| Maximum roll diameter | 18 cm |
| Roll paper | Yes |
| Media thickness (by paper path) | 0.4 mm |
| Recommended media weight | 70 - 328 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32768 MB |
| Internal storage capacity | 160 GB |
| Storage media | HDD |
| Built-in processor | Intel® Celeron® |
| Processor frequency | 1000 MHz |
| Sound power level (standby) | 38 dB |
| Sound pressure level (printing) | 53 dB |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 100 W |
| Power consumption (typical) | 420 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 55 °C |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Compatible operating systems | Windows 7 Ultimate/Professional/Home Premium; Windows Vista Ultimate/Business/Home Premium; Microsoft Windows XP (32-bit, 64-bit) Professional/Home, Server 2008 (32-bit, 64-bit), Server 2003 (32-bit, 64-bit); Mac OS X v10.5, v10.6; Citrix XenApp; Citrix XenServer |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 1974 x 700 x 1374 mm |
| Weight | 187 kg |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 2232 x 761 x 1269 mm |
Other features
| Specification | Value |
|---|---|
| Line accuracy | +/- 0.1% |
| Coated paper | Yes |
| Glossy paper | Yes |
| Photo paper | Yes |
| Roll-up film | Yes |
| Vinyl media | Yes |
| Minimum line width | 0.06 mm |
| Compatible ink types, supplies | Dye-based (C, M, Y, G, DG); pigment-based (mK) |
| Ink drop | 6 pl (C, M, DG, G); 9 pl (Y, mK) |
| Roll maximum input | 3 |
