HP DesignJet Z6200 1067-mm Photo Printer
Model DesignJet Z6200 1067-mm Photo PrinterPart no. CQ109AEAN 8856314072712
35 specifications
- Memory32 MB
- Storage160 GB
- Weight123 kg
- ColourYes
- Maximum print sizeA1 (594 x 841 mm)
- Power consumption (standby)100 W
Overview
- Memory
- 32 MB
- Storage
- 160 GB
- Weight
- 123 kg
- Colour
- Yes
- Maximum print size
- A1 (594 x 841 mm)
- Power consumption (standby)
- 100 W
- Brand
- HP
- Category
- Large Format Printer
- Model
- DesignJet Z6200 1067-mm Photo Printer
- Part number
- CQ109A
- EAN / UPC
- 8856314072712, 885631407240, 885631407257, 885631407264 +3 more
- Also known as
- HP Designjet Z6200 1067-mm Photo Printer large format printer Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
35 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 8 |
| Printing colours | Light Cyan, Light magenta, Magenta, Matte black, Photo black, Yellow |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Banner, Bond paper |
| Media thickness | 0.56 mm |
| Maximum roll length | 175 m |
| Maximum roll diameter | 17 cm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32 MB |
| Internal storage capacity | 160 GB |
| Storage media | HDD |
| Built-in processor | Intel® Celeron® |
| Processor frequency | 1000 MHz |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 100 W |
| Power consumption (typical) | 270 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 55 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 1970 x 690 x 1370 mm |
| Weight | 123 kg |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 2230 x 750 x 1200 mm |
Other features
| Specification | Value |
|---|---|
| Proofing paper | Yes |
| Roll-up film | Yes |
| Roll maximum input | 1 |
