DesignJet Z6 44-in PS Printer
Model DesignJet Z6 44-in PS PrinterPart no. T8W16BEAN 198701770725
59 specifications
- Storage500 GB
- Weight86 kg
- ColourYes
- Print technologyThermal inkjet
- CopyingNo
- Maximum print size1118 x 1676 mm
Overview
- Storage
- 500 GB
- Weight
- 86 kg
- Colour
- Yes
- Print technology
- Thermal inkjet
- Copying
- No
- Maximum print size
- 1118 x 1676 mm
- Brand
- HP
- Category
- Large Format Printer
- Model
- DesignJet Z6 44-in PS Printer
- Part number
- T8W16B
- EAN / UPC
- 198701770725, 198828360670
- Also known as
- HP Designjet Z6 44-in PostScript Printer
Specifications
59 specifications in 14 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Print resolution colour | 2400 x 1200 DPI |
| Number of print cartridges | 6 |
| Page description languages | PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4 |
| Printing colours | Cyan, Photo black, Matte black, Magenta, Yellow |
| Print cartridge volume (metric) | 300 ml |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | No |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | 1118 x 1676 mm |
| Paper tray media types | Coated paper, Bond paper, Photo paper, Banner |
| ISO A-series sizes (A0...A9) | A0, A1, A2, A3, A4 |
| Cut sheets | Yes |
| Media thickness | 0.8 mm |
| Maximum roll width | 111.8 cm |
| Maximum roll diameter | 13.5 cm |
| Print margin cut-sheet | 5 x 17 x 5 x 5 |
| Print margin roll | 5 mm |
| Custom media sizes | 210 x 279 to 1118 x 1676 mm |
| Recommended media weight | 80 - 500 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| USB port | Yes |
| Direct printing | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wi-Fi Direct | Yes |
| Mobile printing technologies | HP ePrint |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Built-in display | Yes |
| Internal storage capacity | 500 GB |
| Country of origin | Singapore, Malaysia |
| Certification | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| HP segment | Business |
Brand-specific features
| Specification | Value |
|---|---|
| HP Dynamic security | Yes |
| HP GTIN (EAN/UPC) | 198701770725 |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.1 W |
| Power consumption (sleep) | 6.5 W |
| Power consumption (typical) | 100 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -25 - 55 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Sustainable technologies and materials | 30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; ENERGY STAR certified; EPEAT registered |
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1802 mm |
| Depth | 695 mm |
| Height | 998 mm |
| Weight | 86 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1950 mm |
| Package depth | 766 mm |
| Package height | 718 mm |
| Package weight | 123 kg |
| Bundled software | HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional) |
Other features
| Specification | Value |
|---|---|
| Electromagnetic compatibility | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| UNSPSC-code | 43212104 |
Technical details
| Specification | Value |
|---|---|
| Box contents | HP DesignJet Z6 PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord |
