Designjet Z5200
Model Designjet Z5200Part no. CQ113AEAN 8849628580974
37 specifications
- Memory32768 MB
- Storage160 GB
- Weight86 kg
- ColourYes
- Maximum print sizeA0 (841 x 1189 mm)
- Power consumption (standby)50 W
Overview
- Memory
- 32768 MB
- Storage
- 160 GB
- Weight
- 86 kg
- Colour
- Yes
- Maximum print size
- A0 (841 x 1189 mm)
- Power consumption (standby)
- 50 W
- Brand
- HP
- Category
- Large Format Printer
- Model
- Designjet Z5200
- Part number
- CQ113A
- EAN / UPC
- 8849628580974, 884962269213, 884962858042, 884962858059 +9 more
- Also known as
- HP Designjet Z5200 large format printer Colour 2400 x 1200 DPI A0 (841 x 1189 mm) Ethernet LAN
Specifications
37 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 8 |
| Page description languages | HP-GL/2, TIFF |
| Print speed (normal quality) | 41 m²/hr |
| Print time black and white line drawing (draft, metric A1 plain paper) | 42.1 |
| Print time colour line drawing (draft, A1) | 42.1 |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A0 (841 x 1189 mm) |
| Media types supported | A4, A3, A2, A1, A0 |
| ISO A-series sizes (A0...A9) | A0, A1, A2, A3, A4 |
| Media thickness | 0.8 mm |
| Maximum roll length | 91 m |
| Maximum roll diameter | 13.5 cm |
| Roll paper | Yes |
| Media thickness (by paper path) | 0.8 mm |
| Recommended media weight | 500 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32768 MB |
| Internal storage capacity | 160 GB |
| Storage media | HDD |
| Processor frequency | 800 MHz |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 50 W |
| Power consumption (typical) | 170 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 0 - 95% |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 7 Home Premium/Professional/Ultimate; Windows Vista Home Premium/Business/Ultimate; Microsoft Windows XP (32-bit, 64-bit) Home/Professional, Server 2003 (32-bit, 64-bit), Server 2008 (32-bit, 64-bit); Novell NetWare 5.x, 6.x; Mac OS X v10.4, v10.5, v10.6; Citrix XenApp; Citrix XenServer |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 86 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 123 kg |
Other features
| Specification | Value |
|---|---|
| Line accuracy | +/- 0.2% |
| Proofing paper | Yes |
| Minimum line width | 0.08 mm |
| Roll maximum input | 1 |
