Designjet T2300
Model Designjet T2300Part no. CN727AEAN 8856314071272
47 specifications
- Memory32768 MB
- Storage160 GB
- Weight103 kg
- ColourYes
- Copier resize25 - 400%
- Hardware scan resolution600 x 600 DPI
Overview
- Memory
- 32768 MB
- Storage
- 160 GB
- Weight
- 103 kg
- Colour
- Yes
- Copier resize
- 25 - 400%
- Hardware scan resolution
- 600 x 600 DPI
- Brand
- HP
- Category
- Large Format Printer
- Model
- Designjet T2300
- Part number
- CN727A
- EAN / UPC
- 8856314071272, 884962223925, 885631407127, 885631407134 +4 more
- Also known as
- HP Designjet T2300 large format printer Colour 2400 x 1200 DPI A0 (841 x 1189 mm) Ethernet LAN
Specifications
47 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 6 |
| Printing colours | Cyan, Magenta, Matte black, Photo black, Yellow |
| Print speed (normal quality) | 51 m²/h |
| Print head nozzles | 1056 |
Copying
| Specification | Value |
|---|---|
| Copier resize | 25 - 400% |
| Maximum number of copies | 99 copies |
Scanning
| Specification | Value |
|---|---|
| Hardware scan resolution | 600 x 600 DPI |
| Scan file formats | TIFF |
| Scan quality (colour, best) | 600 DPI |
| Scan quality (colour, draft) | 200 DPI |
| Scan quality (colour, normal) | 300 DPI |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A0 (841 x 1189 mm) |
| ISO A-series sizes (A0...A9) | A0, A1, A2, A3, A4 |
| Media thickness | 0.8 mm |
| Maximum roll length | 91 m |
| Maximum roll diameter | 13.5 cm |
| Roll paper | Yes |
| Recommended media weight | 60 - 328 g/m² |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32768 MB |
| Internal storage capacity | 160 GB |
| Storage media | HDD |
| Built-in processor | Intel® Pentium® M |
| Processor frequency | 800 MHz |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 41 W |
| Power consumption (typical) | 120 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -25 - 55 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 1771 x 1010 x 1124 mm |
| Weight | 103 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 135 g |
| Package dimensions (WxDxH) | 1930 x 766 x 827 mm |
Other features
| Specification | Value |
|---|---|
| Line accuracy | +/- 0.1% |
| Coated paper | Yes |
| Maximum scan size | 914 x 2378 mm |
| Photo paper | Yes |
| Acoustic pressure emissions | 43 dB |
| Roll maximum input | 2 |
