DesignJet T230 24-in Printer
Model DesignJet T230 24-in PrinterPart no. 5HB07D#B19EAN 198701026570
63 specifications
- Memory512 MB
- Weight21.5 kg
- ColourYes
- Print technologyThermal inkjet
- CopyingNo
- Maximum print sizeA1 (594 x 841 mm)
Overview
- Memory
- 512 MB
- Weight
- 21.5 kg
- Colour
- Yes
- Print technology
- Thermal inkjet
- Copying
- No
- Maximum print size
- A1 (594 x 841 mm)
- Brand
- HP
- Category
- Large Format Printer
- Model
- DesignJet T230 24-in Printer
- Part numbers
- 5HB07D#B19, 5HB07A, 5HB07A#B19, 5HB07D, 5HB07T
- EAN / UPC
- 198701026570, 193015779273, 194850019722, 194850019739 +14 more
- Also known as
- HP Designjet T230 24-in Printer
Specifications
63 specifications in 15 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Print resolution colour | 2400 x 1200 DPI |
| Number of print cartridges | 4 |
| Page description languages | JPEG, URF |
| Printing colours | Black, Cyan, Magenta, Yellow |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | No |
| Accuracy | 0.1% |
| Maximum media thickness | 0.3 mm |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Coated paper, Plain paper, Semi-glossy paper, Glossy paper, Bond paper, Photo paper, Matte paper, Heavy paper, Satin paper |
| ISO A-series sizes (A0...A9) | A1, A2, A3, A4 |
| Cut sheets | No |
| Maximum roll width | 61 cm |
| Maximum roll diameter | 27.9 cm |
| Custom media sizes | 210 x 279 to 610 x 1897 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB 2.0 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Built-in display | No |
| Internal memory | 512 MB |
| Country of origin | China |
| Certification | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/RED Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class B product: Korea (KCC) |
| HP segment | Business |
Brand-specific features
| Specification | Value |
|---|---|
| HP Dynamic security | Yes |
| HP GTIN (EAN/UPC) | 194850019715 |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.2 W |
| Power consumption (sleep) | 2.1 W |
| Power consumption (standby) | 0.2 W |
| Power consumption (typical) | 35 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 3000 m |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -25 - 55 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, Forest Stewardship Council (FSC) |
| Sustainable technologies and materials | More sustainable design reduces CO2e up to 7.3 tons/year by units sold by using up to 30% UL Validated recycled plastic.; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; FSC-certified papers and a range of recyclable HP media with a take-back program; ENERGY STAR c |
| Sustainability compliance | Yes |
Carbon footprint
| Specification | Value |
|---|---|
| Total carbon footprint (kg of CO2e) | 202 |
| Carbon emissions, manufacturing (kg of CO2e) | 176 |
| Carbon emissions, logistics (kg of CO2e) | 11 |
| Carbon emissions, end-of-life (kg of CO2e) | 11 |
| Total carbon emissions, w/o use phase (kg of CO2e) | 4 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1013 mm |
| Depth | 440 mm |
| Height | 285 mm |
| Weight | 21.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1155 mm |
| Package depth | 575 mm |
| Package height | 405 mm |
| Package weight | 28 kg |
| Bundled software | HP Click App, HP Click Driver for Windows 11, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant |
Other features
| Specification | Value |
|---|---|
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/RED Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class B product: Korea (KCC) |
| UNSPSC-code | 43212104 |
Technical details
| Specification | Value |
|---|---|
| General Product Safety Regulation (GPSR) URL | https://support.hp.com/gb-en/product/setup-user-guides/hp-designjet-t230-printer/model/33508832?sku=5HB07A ; https://h10032.www1.hp.com/ctg/Manual/c06880937.pdf |
| Box contents | HP DesignJet T230 24-in Printer, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord |
