110plus r
Model 110plus rPart no. C7796HEAN 8844207071416
53 specifications
- Memory64 MB
- Weight23 kg
- ColourYes
- Print technologyThermal inkjet
- Total number of input trays1
- Maximum print size625 x 1625 mm
Overview
- Memory
- 64 MB
- Weight
- 23 kg
- Colour
- Yes
- Print technology
- Thermal inkjet
- Total number of input trays
- 1
- Maximum print size
- 625 x 1625 mm
- Brand
- HP
- Category
- Large Format Printer
- Model
- 110plus r
- Part number
- C7796H
- EAN / UPC
- 8844207071416, 884420677390, 884420707141, 884420707158 +6 more
- Also known as
- HP Designjet 110plus r large format printer Thermal inkjet Colour 1200 x 600 DPI 625 x 1625 mm
Specifications
53 specifications in 11 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Thermal inkjet |
| Colour | Yes |
| Maximum resolution | 1200 x 600 DPI |
| Number of print cartridges | 4 |
| Page description languages | PCL 3 |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Maximum duty cycle | 7000 pages per month |
Input & output capacity
| Specification | Value |
|---|---|
| Total number of input trays | 1 |
| Total input capacity | 150 sheets |
| Total output capacity | 50 sheets |
| Maximum input capacity | 150 sheets |
| Maximum output capacity | 50 sheets |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | 625 x 1625 mm |
| Paper tray media types | Bond paper, Coated paper, Glossy paper, Matte paper, Semi-glossy paper |
| ISO A-series sizes (A0...A9) | A1, A2, A3, A4 |
| ISO B-series sizes (B0...B9) | B2, B3, B4 |
| Cut sheets | Yes |
| Maximum roll length | 15.2 m |
| Print margin cut-sheet | 5 x 12 mm |
| Print margin roll | 5 mm |
| Media width (sheets) | 625 mm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB port | Yes |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Parallel ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Product colour | Grey |
| Built-in display | Yes |
| Display | LCD |
| Internal memory | 64 MB |
| Maximum internal memory | 64 MB |
| Built-in processor | Yes |
| Processor frequency | 16 MHz |
| Sound power level (standby) | 5.4 dB |
| Sound pressure level (printing) | 37 dB |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 14 W |
| Power consumption (typical) | 48 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -20 - 55 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1042 mm |
| Depth | 535 mm |
| Height | 220 mm |
| Weight | 23 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1192 mm |
| Package depth | 545 mm |
| Package height | 493 mm |
| Package weight | 34.3 kg |
| Drivers included | Yes |
Other features
| Specification | Value |
|---|---|
| Print speed (colour, draft quality, A4/US Letter) | 11 ppm |
| Proofing paper | Yes |
