SureColor T5170M large format printer Wi-Fi Inkjet Colour
2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Model T5170MPart no. SCT5170MEAN 010343963115
37 specifications
- Display10.9 cm (4.3")
- Weight56 kg
- ColourYes
- Print technologyInkjet
- CopyingNo
- ScanningColour scanning
Overview
- Display
- 10.9 cm (4.3")
- Weight
- 56 kg
- Colour
- Yes
- Print technology
- Inkjet
- Copying
- No
- Scanning
- Colour scanning
- Brand
- Epson
- Category
- Large Format Printer
- Model
- T5170M
- Part number
- SCT5170M
- EAN / UPC
- 010343963115
- Also known as
- Epson SureColor T5170M large format printer Wi-Fi Inkjet Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
37 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | ESC P, HP-GL/2, HP-RTL |
| Printing colours | Black, Cyan, Magenta, Yellow |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | Colour scanning |
| Maximum scan resolution | 2400 x 2100 DPI |
| Scanner type | Sheet-fed scanner |
| Scan technology | CIS |
| Scan to | E-mail Server, FTP, USB |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Coated paper, Plain paper, Recycled paper, Roll |
| Cut sheets | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| Wi-Fi Direct | Yes |
Performance
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Control type | Touch |
| Sound pressure level (printing) | 49 dB |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.2 W |
| Power consumption (sleep) | 2 W |
| Power consumption (typical) | 26 W |
| AC input voltage | 110 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1270 mm |
| Depth | 609.6 mm |
| Height | 990.6 mm |
| Weight | 56 kg |
