SureColor T5160 large format printer Wi-Fi Inkjet Colour
2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Model T5160Part no. C11CF12409EAN 9314020625329
39 specifications
- Display10.9 cm (4.3")
- Memory1024 MB
- Weight46 kg
- ColourYes
- Print technologyInkjet
- Maximum print sizeA1 (594 x 841 mm)
Overview
- Display
- 10.9 cm (4.3")
- Memory
- 1024 MB
- Weight
- 46 kg
- Colour
- Yes
- Print technology
- Inkjet
- Maximum print size
- A1 (594 x 841 mm)
- Brand
- Epson
- Category
- Large Format Printer
- Model
- T5160
- Part number
- C11CF12409
- EAN / UPC
- 9314020625329
- Also known as
- Epson SureColor T5160 large format printer Wi-Fi Inkjet Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
39 specifications in 8 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | HP-GL/2, ESC/P-P |
| Printing colours | Black, Yellow, Cyan, Magenta |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Roll |
| ISO A-series sizes (A0...A9) | A1, A3, A4 |
| ISO B-series sizes (B0...B9) | B5 |
| Cut sheets | Yes |
| Maximum roll diameter | 11 cm |
| Roll weight (rear roll) | 5 kg |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi Direct | Yes |
| Mobile printing technologies | Apple AirPrint |
Performance
| Specification | Value |
|---|---|
| Product colour | Black, Grey |
| Built-in display | Yes |
| Display | LCD |
| Colour display | Yes |
| Display diagonal | 10.9 cm (4.3") |
| Control type | Touch |
| Internal memory | 1024 MB |
Power
| Specification | Value |
|---|---|
| Power consumption (sleep) | 1.6 W |
| Power consumption (standby) | 8 W |
| Power consumption (typical) | 28 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 10, Windows 8, Windows 7, Windows Vista, Windows 8.1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1268 mm |
| Depth | 696 mm |
| Height | 913 mm |
| Weight | 46 kg |
