Epson SureColor T3170 large format printer Wi-Fi Inkjet Colour
2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Model T3170Part no. SCT3170SREAN 010343945418
55 specifications
- Display10.9 cm (4.3")
- Weight27 kg
- ColourYes
- Print technologyInkjet
- CopyingNo
- Maximum print sizeA1 (594 x 841 mm)
Overview
- Display
- 10.9 cm (4.3")
- Weight
- 27 kg
- Colour
- Yes
- Print technology
- Inkjet
- Copying
- No
- Maximum print size
- A1 (594 x 841 mm)
- Brand
- Epson
- Category
- Large Format Printer
- Model
- T3170
- Part number
- SCT3170SR
- EAN / UPC
- 010343945418
- Also known as
- Epson SureColor T3170 large format printer Wi-Fi Inkjet Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
55 specifications in 13 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | ESC P, HP-GL/2, HP-RTL |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Print head | PrecisionCore |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | No |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| ISO A-series sizes (A0...A9) | A1 |
| Cut sheets | Yes |
| Media thickness | 0.05 - 0.27 mm |
| Maximum roll diameter | 10.9 cm |
| Print margin cut-sheet | 203.2 x 279.4 mm |
| Roll top margin | 3 mm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | No |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| Direct printing | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Product colour | White |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Control type | Touch |
| Sound power level (standby) | 32 dB |
| Sound pressure level (printing) | 49 dB |
| Country of origin | Indonesia |
| Certification | RoHS |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.2 W |
| Power consumption (standby) | 8 W |
| Power consumption (typical) | 28 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 20 - 80 °C |
| Operating relative humidity (H-H) | -4 - 104% |
| Storage relative humidity (H-H) | 5 - 85% |
| Storage temperature (T-T) | 50 - 95 °C |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 10.0 Cheetah, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1, Windows Vista, Windows XP |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 970 mm |
| Depth | 505 mm |
| Height | 230 mm |
| Weight | 27 kg |
| Stand weight | 11 kg |
Packaging data
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Manual | Yes |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Touchscreen | Yes |
| Safety | UL (MET), FCC (Class A), CSA, CE, EMC |
