Stylus Pro 9700
Model Stylus Pro 9700Part no. C11CA59001A0EAN 010343874305
48 specifications
- Display5.99 cm (2.36")
- Memory256 MB
- Weight115 kg
- ColourYes
- Print technologyInkjet
- Maximum print sizeB0 (1000 x 1414 mm)
Overview
- Display
- 5.99 cm (2.36")
- Memory
- 256 MB
- Weight
- 115 kg
- Colour
- Yes
- Print technology
- Inkjet
- Maximum print size
- B0 (1000 x 1414 mm)
- Brand
- Epson
- Category
- Large Format Printer
- Model
- Stylus Pro 9700
- Part number
- C11CA59001A0
- EAN / UPC
- 010343874305, 010343878570, 8715946453224
- Also known as
- Epson Stylus Pro 9700
Specifications
48 specifications in 11 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2880 x 2880 DPI |
| Number of print cartridges | 5 |
| Page description languages | Epson ESC/P2 |
| Printing colours | Photo black, Matte black, Vivid magenta, Yellow, Cyan |
| Print head | TFP |
| Print head nozzles | 360 Nozzles Black, 360 Nozzles per Color |
| Colour printing technology | Ultrachrome® |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | B0 (1000 x 1414 mm) |
| Paper tray media types | Roll |
| ISO A-series sizes (A0...A9) | A0, A1, A2, A3+, A3, A4 |
| ISO B-series sizes (B0...B9) | B4, B3, B2, B1 |
| Media thickness | 0.08 - 1.5 mm |
| Media width (rolls) | 406 - 1118 mm |
| Media width (sheets) | 210 - 1118 mm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN data rates | 10/100 Base-TX |
Performance
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Colour display | Yes |
| Display diagonal | 5.99 cm (2.36") |
| Internal memory | 256 MB |
| Sound pressure level (printing) | 50 dB |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 1 W |
| Power consumption (typical) | 80 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS 10.3+, Windows 7, Windows 7 x64, Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, Windows Server 2003 R2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 1864 x 667 x 1218 mm |
| Width | 1864 mm |
| Depth | 667 mm |
| Height | 1209 mm |
| Weight | 115 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 800 mm |
| Package depth | 2030 mm |
| Package height | 1080 mm |
| Package weight | 195 kg |
Other features
| Specification | Value |
|---|---|
| Ink drop | 3.5 pl |
Logistics data
| Specification | Value |
|---|---|
| Products per pallet | 1 pc(s) |
| Quantity per pack | 1 pc(s) |
Technical details
| Specification | Value |
|---|---|
| Box contents | Driver and utilities, Individual Ink Cartridges, Main unit, Power cable, Setup guide, User manual (CD) |
| Power consumption | 70 Watt, 16 Watt (economy), 1 Watt (Power off) |
