SureColor SC-T3405N large format printer Wi-Fi Inkjet Colour
2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Model SC-T3405NPart no. C11CJ55302A0EAN 8715946687025
62 specifications
- Display10.9 cm (4.3")
- Memory1024 MB
- Weight49 kg
- ColourYes
- Print technologyInkjet
- Maximum print sizeA1 (594 x 841 mm)
Overview
- Display
- 10.9 cm (4.3")
- Memory
- 1024 MB
- Weight
- 49 kg
- Colour
- Yes
- Print technology
- Inkjet
- Maximum print size
- A1 (594 x 841 mm)
- Brand
- Epson
- Category
- Large Format Printer
- Model
- SC-T3405N
- Part numbers
- C11CJ55302A0, C11CJ55302A1
- EAN / UPC
- 8715946687025, 8715946687032
- Also known as
- Epson SureColor SC-T3405N large format printer Wi-Fi Inkjet Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
62 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | ESC/P-R, HP-GL/2, HP-RTL |
| Printing colours | Black, Cyan, Yellow, Magenta |
| Borderless printing | Yes |
| Print head nozzles | 800 nozzles black, 800 nozzles per colour |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Roll |
| ISO A-series sizes (A0...A9) | A1, A2, A3, A3+, A4 |
| ISO B-series sizes (B0...B9) | B1, B2, B3, B4, B5 |
| Cut sheets | Yes |
| Media thickness | 0.05 - 0.3 mm |
| Maximum roll width | 61 cm |
| Print margin cut-sheet | 3 x 3 x 20 x 3 |
| Print margin roll | 3 mm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| Direct printing | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Supported network protocols | TLS, SSL, IEE 802, SNMP, IPSec, IPv6 |
| Mobile printing technologies | Apple AirPrint |
| Security algorithms | SSL/TLS, SNMP, IPSec |
Performance
| Specification | Value |
|---|---|
| Product colour | White |
| Built-in display | Yes |
| Display | LCD |
| Colour display | Yes |
| Display diagonal | 10.9 cm (4.3") |
| Control type | Touch |
| Internal memory | 1024 MB |
| Sound pressure level (standby) | 32 dB |
| Sound power level (standby) | 32 dB |
| Sound pressure level (printing) | 50 dB |
| Country of origin | Indonesia |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.25 W |
| Power consumption (standby) | 13 W |
| Power consumption (typical) | 38 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS X 10.6.8 or later, Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Mac operating systems supported | Mac OS X 10.6 Snow Leopard |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1080 mm |
| Depth | 750 mm |
| Height | 1060 mm |
| Weight | 49 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 853 mm |
| Package depth | 1250 mm |
| Package height | 1107 mm |
| Package weight | 78 kg |
| Cartridge(s) included | Yes |
| Drivers included | Yes |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Line accuracy | +/- 0,1 |
| Touchscreen | Yes |
| Compatible products | WorkForce DS-6500, WorkForce DS-60000 |
| Minimum line width | 0.02 mm |
| Ink drop | 4 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Quantity per pack | 1 pc(s) |
