SureColor SC-S80610L large format printer Inkjet Colour
1440 x 1440 DPI Ethernet LAN
Model SC-S80610LPart no. C11CH24302A0EAN 8715946676333
45 specifications
- Memory2048 MB
- Weight328 kg
- ColourYes
- Print technologyInkjet
- CopyingNo
- Paper tray media typesRoll
Overview
- Memory
- 2048 MB
- Weight
- 328 kg
- Colour
- Yes
- Print technology
- Inkjet
- Copying
- No
- Paper tray media types
- Roll
- Brand
- Epson
- Category
- Large Format Printer
- Model
- SC-S80610L
- Part number
- C11CH24302A0
- EAN / UPC
- 8715946676333
- Also known as
- Epson SureColor SC-S80610L large format printer Inkjet Colour 1440 x 1440 DPI Ethernet LAN
Specifications
45 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 1440 x 1440 DPI |
| Number of print cartridges | 11 |
| Page description languages | ESC/P-R |
| Printing colours | Black, Cyan, Light black, Light Cyan, Light magenta, Magenta, Metallic silver, Orange, Red, White, Yellow |
| Print cartridge volume (metric) | 1500 ml |
| Print head | Micro Piezo TFP |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | No |
Paper handling
| Specification | Value |
|---|---|
| Paper tray media types | Roll |
| Cut sheets | No |
| Media thickness | 1 mm |
| Maximum roll width | 162.6 cm |
| Print margin roll | 5 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| USB port | Yes |
| USB connector | USB Type-A / USB Type-B |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Built-in display | Yes |
| Colour display | Yes |
| Internal memory | 2048 MB |
| Sound pressure level (printing) | 59 dB |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power consumption (PowerSave) | 400 W |
| Power consumption (off) | 1.5 W |
| Power consumption (standby) | 24 W |
| Power consumption (typical) | 640 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS 10.6+, Windows 10, Windows 10 (32/64 bit), Windows 7, Windows 7 x64, Windows 8, Windows 8 (32/64 bit), Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, XP Professional x64 Edition, XP Professional x64 Edition SP2 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 2766 mm |
| Depth | 1090 mm |
| Height | 1671 mm |
| Weight | 328 kg |
Packaging data
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
| Drivers included | Yes |
| Manual | Yes |
| Quick start guide | Yes |
| Bundled software | Epson Edge Print |
Other features
| Specification | Value |
|---|---|
| Ink drop | 4.9 pl |
Technical details
| Specification | Value |
|---|---|
| Box contents | Bulk Ink Solution, Driver and utilities (CD), Individual Ink Cartridges, Installation/safety manual, Power cable, Warranty Documents |
