TM-240 Lm MFP
Model TM-240 Lm MFPPart no. BDL_TM240LM MFP
44 specifications
- Display10.9 cm (4.3")
- Memory2000 MB
- ColourYes
- Print technologyInkjet
- CopyingNo
- ScanningColour scanning
Overview
- Display
- 10.9 cm (4.3")
- Memory
- 2000 MB
- Colour
- Yes
- Print technology
- Inkjet
- Copying
- No
- Scanning
- Colour scanning
- Brand
- Canon
- Category
- Large Format Printer
- Model
- TM-240 Lm MFP
- Part number
- BDL_TM240LM MFP
- Also known as
- Canon imagePROGRAF TM-240 Lm MFP large format printer Wi-Fi Inkjet Colour 2400 x 1200 DPI A1 (594 x 841 mm) Ethernet LAN
Specifications
44 specifications in 11 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Number of print cartridges | 5 |
| Page description languages | CALS G4, HP-GL/2, HP-RTL, JPEG |
| Printing colours | Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow |
| Borderless printing | Yes |
| Print head nozzles | 15360 |
Copying
| Specification | Value |
|---|---|
| Copying | No |
Scanning
| Specification | Value |
|---|---|
| Scanning | Colour scanning |
| Maximum scan resolution | 600 x 600 DPI |
| Maximum scan length | 2.77 m |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A1 (594 x 841 mm) |
| Paper tray media types | Cut sheet, Roll |
| Borderless printing media sizes | A1, A2, A3, A3+, B2, B4 |
| Cut sheets | Yes |
| Media thickness | 0.07 - 0.8 mm |
| Maximum roll diameter | 15 cm |
| Print margin cut-sheet | 20, 31, 3 mm |
| Print margin roll | 2 cm |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| USB port | Yes |
| USB connector | USB Type-B |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Mobile printing technologies | Apple AirPrint |
Performance
| Specification | Value |
|---|---|
| Product colour | Black, Grey |
| Built-in display | Yes |
| Display diagonal | 10.9 cm (4.3") |
| Control type | Touch |
| Internal memory | 2000 MB |
| Sound pressure level (standby) | 35 dB |
| Sound pressure level (printing) | 39 dB |
Power
| Specification | Value |
|---|---|
| Power consumption (off) | 0.1 W |
| Power consumption (sleep) | 2.2 W |
| Power consumption (typical) | 59 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 15 - 30 °C |
| Operating relative humidity (H-H) | 10 - 80% |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8.1 |
Packaging data
| Specification | Value |
|---|---|
| Cartridge(s) included | Yes |
Other features
| Specification | Value |
|---|---|
| Line accuracy | 0.1% |
