imagePROGRAF iPF760 large format printer Inkjet Colour
2400 x 1200 DPI A0 (841 x 1189 mm) Ethernet LAN
Model iPF760Part no. 6470B003EAN 4960999901169
37 specifications
- Weight64 kg
- ColourYes
- Print technologyInkjet
- Maximum print sizeA0 (841 x 1189 mm)
- Product colourBlack, White
- Power supply typeAC
Overview
- Weight
- 64 kg
- Colour
- Yes
- Print technology
- Inkjet
- Maximum print size
- A0 (841 x 1189 mm)
- Product colour
- Black, White
- Power supply type
- AC
- Brand
- Canon
- Category
- Large Format Printer
- Model
- iPF760
- Part numbers
- 6470B003, 1951V396, 6470B002
- EAN / UPC
- 4960999901169, 8714574570587, 013803150063, 138031500630
- Also known as
- Canon imagePROGRAF iPF760 large format printer Inkjet Colour 2400 x 1200 DPI A0 (841 x 1189 mm) Ethernet LAN
Specifications
37 specifications in 9 groups
Printing
| Specification | Value |
|---|---|
| Print technology | Inkjet |
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | GARO |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Print head | PF-04 |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A0 (841 x 1189 mm) |
| ISO A-series sizes (A0...A9) | A0, A1 |
| ISO B-series sizes (B0...B9) | B2 |
| Borderless printing media sizes | A1, A0 |
| Cut sheets | Yes |
| Media thickness | 0.07 - 0.8 mm |
| Maximum roll length | 18 m |
| Maximum roll diameter | 15 cm |
| Media width (rolls) | 254 - 914 mm |
| Media width (sheets) | 203.2 - 914 mm |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| Ethernet interface type | Gigabit Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN data rates | 10/100/1000 Base-T/TX |
Performance
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Sound pressure level (printing) | 50 dB |
Power
| Specification | Value |
|---|---|
| Power supply type | AC |
| Power requirements | 100 - 240V, 50/60Hz |
| Power consumption (off) | 5 W |
| Power consumption (standby) | 5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 15 - 30 °C |
| Operating relative humidity (H-H) | 10 - 80% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1303 mm |
| Depth | 1099.8 mm |
| Height | 1061.7 mm |
| Weight | 64 kg |
Packaging data
| Specification | Value |
|---|---|
| Drivers included | Yes |
