imagePROGRAF iPF-510 large format printer Colour
2400 x 1200 DPI A2 (420 x 594 mm) Ethernet LAN
Model iPF-510Part no. 2158B003EAN 4960999489346
53 specifications
- Memory192 MB
- Weight39 kg
- ColourYes
- Maximum print sizeA2 (420 x 594 mm)
- Power requirementsAC 100-240V (50/60 Hz)
- Operating relative humidity (H-H)10 - 80%
Overview
- Memory
- 192 MB
- Weight
- 39 kg
- Colour
- Yes
- Maximum print size
- A2 (420 x 594 mm)
- Power requirements
- AC 100-240V (50/60 Hz)
- Operating relative humidity (H-H)
- 10 - 80%
- Brand
- Canon
- Category
- Large Format Printer
- Model
- iPF-510
- Part number
- 2158B003
- EAN / UPC
- 4960999489346
- Also known as
- Canon imagePROGRAF iPF-510 large format printer Colour 2400 x 1200 DPI A2 (420 x 594 mm) Ethernet LAN
Specifications
53 specifications in 10 groups
Printing
| Specification | Value |
|---|---|
| Colour | Yes |
| Maximum resolution | 2400 x 1200 DPI |
| Page description languages | GARO, HP-RTL |
| Printing colours | Black, Cyan, Magenta, Yellow |
| Print head | PF-03 |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A2 (420 x 594 mm) |
| Paper tray media types | Banner, Cut sheet, Matte paper, Plain paper, Roll |
| ISO A-series sizes (A0...A9) | A2, A3, A4 |
| ISO B-series sizes (B0...B9) | B3, B4 |
| Borderless printing media sizes | Legal, Letter |
| Cut sheets | Yes |
| Media thickness | 0.07 - 0.8 mm |
| Maximum roll length | 18 m |
| Architectural sizes | 8”, 10”, 14”, 16”, 17” |
| JIS B-series sizes (B0...B9) | B4 |
| Maximum media width | 203 - 432 mm |
| Media width (rolls) | 203 - 432 mm |
| Photo paper sizes (imperial) | 8x10,10x12,10x15,12x16,14x17,16x20 |
| Roll paper | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| USB port | Yes |
| Ethernet interface type | Fast Ethernet |
| USB connector | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN data rates | 10Base-T, 100base-TX |
| Supported network protocols | IPX/SPX, SNMP HTTP, TCP/IP, AppleTalk |
| RJ-45 ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Internal memory | 192 MB |
| Sound power level (standby) | 35 dB |
| Sound pressure level (printing) | 52 dB |
| Certification | RoHS, IT ECO, WEEE, CE, TUV, GS, Gost-R, CB |
Power
| Specification | Value |
|---|---|
| Power requirements | AC 100-240V (50/60 Hz) |
| Power consumption (off) | 1 W |
| Power consumption (standby) | 6 W |
| Power consumption (typical) | 100 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Storage temperature (T-T) | 15 - 30 °C |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 819 x 733 x 317 mm |
| Weight | 39 kg |
| Size (imperial) | 43.2 cm (17") |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 57 kg |
| Package dimensions (WxDxH) | 960 x 874 x 638 mm |
Other features
| Specification | Value |
|---|---|
| Line accuracy | +/-0.1% |
| Coated paper | Yes |
| Compliance industry standards | IEEE 802.3, 802.3u |
| Glossy paper | Yes |
| High resolution paper | Yes |
| Opaque paper | Yes |
| Photo paper | Yes |
| Proofing paper | Yes |
