Lenovo 520 + WM
Lenovo

520 + WM

Model 520 + WMPart no. 81C800GAAX+WM

152 specifications Checked today
  • Display35.6 cm (14")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i3
  • Memory4 GB
  • Storage1 TB
  • GraphicsNot available
See all specifications

Overview

Display
35.6 cm (14")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i3
Memory
4 GB
Storage
1 TB
Graphics
Not available
Brand
Lenovo
Category
Laptop
Model
520 + WM
Part number
81C800GAAX+WM
Also known as
Lenovo Yoga 520 + WM Intel® Core™ i3 i3-8130U Hybrid (2-in-1) 35.6 cm (14") Touchscreen Full HD 4 GB DDR4-SDRAM 1 TB HDD Wi-Fi 5 (802.11ac) Windows 10 Home Gold

Specifications

152 specifications in 22 groups

Design

Product typeHybrid (2-in-1)
Product colourGold
Form factorConvertible (Folder)

Display

Display diagonal35.6 cm (14")
Display resolution1920 x 1080 pixels
TouchscreenYes
Touchscreen typeCapacitive
HD typeFull HD
Touch technologyMulti-touch
Panel typeIPS
LED backlightYes
Native aspect ratio16:9
Display brightness250 cd/m²

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation8th gen Intel® Core™ i3
Processor modeli3-8130U
Processor cores2
Processor threads4
Processor boost frequency3.4 GHz
Processor frequency2.2 GHz
System bus rate4 GT/s
Processor cache4 MB
Processor cache typeSmart Cache
Processor lithography14 nm
Processor operating modes64-bit
Processor codenameKaby Lake
Thermal Design Power (TDP)15 W
Configurable TDP-down10 W
Configurable TDP-down frequency0.8 GHz
Tjunction100 °C
Maximum number of PCI Express lanes12
PCI Express configurations1x2+2x1, 1x4, 2x2, 4x1
PCI Express slots version3.0
ECC supported by processorNo

Memory

Internal memory4 GB
Internal memory typeDDR4-SDRAM
Memory form factorSO-DIMM
Memory layout (slots x size)1 x 4 GB
Memory slots1x SO-DIMM
Maximum internal memory16 GB
Maximum internal memory (64-bit)16 GB

Storage

Total storage capacity1 TB
Storage mediaHDD
Total HDDs capacity1 TB
Number of HDDs installed1
HDD capacity1 TB
HDD speed5400 RPM
HDD size2.5"
Optical drive typeNo
Card reader integratedYes
Compatible memory cardsMMC, SD, SDHC, SDXC

Graphics

On-board graphics cardYes
Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics card familyIntel® UHD Graphics
On-board graphics card modelIntel® UHD Graphics 620
Maximum on-board graphics card memory32 GB
On-board graphics card base frequency300 MHz
On-board graphics card dynamic frequency (max)1000 MHz
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.4

Audio

Audio systemDolby Home Theater
Number of built-in speakers2
Speakers manufacturerHarman Kardon
Speaker power1.5 W
Built-in microphoneYes

Camera

Front cameraYes
Front camera resolution (numeric)1 MP
Front camera signal format720p
Auto focusNo

Network

Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antenna type1x1
Ethernet LANNo
BluetoothYes
Bluetooth version4.1
WWANNot installed

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Ethernet LAN (RJ-45) ports0
HDMI ports quantity1
DisplayPorts quantity0
DVI portNo
VGA (D-Sub) ports quantity0
Thunderbolt ports quantity0
Thunderbolt 3 ports quantity0
Headphone outputs1
Combo headphone/mic portYes
Microphone inNo
Docking connectorNo
USB Sleep-and-ChargeYes
USB Sleep-and-Charge ports1

Performance

AccelerometerYes

Keyboard

Pointing deviceTouchpad
Keyboard backlitYes
Numeric keypadNo
Windows keysYes

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Flex Memory AccessYes
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)Yes
Intel TSX-NINo
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® My WiFi Technology (Intel® MWT)Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Smart Response TechnologyYes
Intel® Turbo Boost Technology2.0
Processor ARK ID137977
Processor package size42 x 42 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes

Battery

Battery technologyLithium-Ion (Li-Ion)
Battery capacity52.5 Wh
Battery life (max)10 h

Power

AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V

Security

Cable lock slotYes
Fingerprint readerYes
Trusted Platform Module (TPM)Yes
Password protectionYes
Password protection typeHDD, Power on, Supervisor

Certificates

Compliance certificatesRoHS

Sustainability

Sustainability certificatesEPEAT Silver, ENERGY STAR

Weight & dimensions

Weight1.7 kg
Width328 mm
Depth229 mm
Height19.9 mm

Packaging content

ManualYes

Other features

3DNo
