HP Pavilion Plus 16-ab0501na

Pavilion Plus 16-ab0501na

Model Pavilion Plus 16-ab0501naPart no. A14DFEAEAN 198122709724

141 specifications Checked today

Display40.6 cm (16")
Resolution2560 x 1600 pixels
ProcessorIntel® Core™ i5
Memory16 GB
Storage512 GB
GraphicsNVIDIA GeForce RTX 3050

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 2560 x 1600 pixels
Processor: Intel® Core™ i5
Memory: 16 GB
Storage: 512 GB
Graphics: NVIDIA GeForce RTX 3050

Brand: HP
Category: Laptop
Model: Pavilion Plus 16-ab0501na
Part number: A14DFEA
EAN / UPC: 198122709724
Also known as: HP Pavilion Plus 16-ab0501na Intel® Core™ i5 i5-13500H Laptop 40.6 cm (16") WQXGA 16 GB LPDDR5x-SDRAM 512 GB SSD NVIDIA GeForce RTX 3050 Wi-Fi 6E (802.11ax) Win

Specifications

141 specifications in 25 groups

Design

Specification	Value
Product type	Laptop
Product colour	Silver
Colour name	Natural silver aluminum
Form factor	Clamshell
Market positioning	Everyday
Introduction year	2024
Original brand name	HP

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	2560 x 1600 pixels
Touchscreen	No
HD type	WQXGA
Panel type	IPS
Native aspect ratio	16:10
Anti-glare screen	Yes
Display bezel technology	Micro-Edge
Display brightness	400 cd/m²
Colour gamut	100%
Display diagonal (metric)	40.6 cm
RGB colour space	sRGB
Maximum refresh rate	120 Hz

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	13th gen Intel® Core™ i5
Processor model	i5-13500H
Processor cores	12
Processor threads	16
Processor boost frequency	4.7 GHz
Performance cores	4
Efficient cores	8
Performance-core Max Turbo Frequency	4.7 GHz
Efficient-core Max Turbo Frequency	3.5 GHz
Processor cache	18 MB
Processor cache type	L3
Maximum turbo power	95 W
Processor base power	45 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	5200 MHz
Memory form factor	On-board
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 3050
Discrete graphics card memory	6 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	Intel
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics

Audio

Specification	Value
Audio system	B&O PLAY
Built-in speaker(s)	Yes
Number of built-in speakers	2
Speakers manufacturer	Bang & Olufsen
Built-in microphone	Yes
Number of microphones	2

Camera

Specification	Value
Front camera	Yes
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
WLAN controller model	Intel Wi-Fi 6E AX211
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge	Yes
USB Sleep-and-Charge ports	2

Performance

Specification	Value
Motherboard chipset	Intel SoC

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	No
Full-size keyboard	Yes
Keyboard colour name	soft grey

Software

Specification	Value
Operating system installed	Windows 11 Home
Pre-installed software	Intel® Unison™, 1 month trial for new Microsoft 365 customers, McAfee Online Protection 30-day trial; 1-month Adobe free trial offer; Xbox Game Pass 1-month free trial; PC Game Pass 3-month trial
Trial software	25 GB Dropbox storage for 12 months

Brand-specific features

Specification	Value
HP Audio Boost	Yes
HP speaker type	HP Dual Speakers
HP Imagepad	Yes
HP front camera	HP Wide Vision 5MP
HP Security tools	Mic mute key; Camera privacy shutter; Trusted Platform Module (Firmware TPM) support
HP Software provided	HP Support Assistant; HP Connection Optimizer; OMEN Gaming Hub; HP Enhanced Lighting; HP Presence; myHP
HP segment	Home
HP GTIN (EAN/UPC)	198122709724

Battery

Specification	Value
Battery technology	Lithium Polymer (LiPo)
Number of battery cells	4
Battery capacity	68 Wh
Battery life (max)	11.75 h
Continuous video playback time (max)	15.75 h
Fast charging	Yes
Fast charging time (50%)	30 min

Power

Specification	Value
AC adapter power	135 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	BIOS, Power on, User

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Gold
Sustainable technologies and materials	Ocean-bound plastic in speaker enclosure(s) and bezel; Keyboard keycaps and scissors contain post-consumer recycled plastic; Recycled metal in cover, keyboard frame, base, sideband, hinge cap(s) and keyboard supporting plate
Sustainability compliance	Yes

Weight & dimensions

Specification	Value
Weight	1.89 kg
Width	357 mm
Depth	253.5 mm
Height (front)	1.77 cm
Height (rear)	1.99 cm

Packaging data

Specification	Value
Package width	69 mm
Package depth	552 mm
Package height	345 mm
Package weight	2.7 kg

Carbon footprint

Specification	Value
Carbon emissions, logistics (kg of CO2e)	4
Carbon emissions, manufacturing (kg of CO2e)	154
Total carbon emissions, w/o use phase (kg of CO2e)	26
Total carbon footprint (kg of CO2e)	180

Packaging content

Specification	Value
Stylus pen	No

Logistics data

Specification	Value
Harmonized System (HS) code	8471300000

Technical details

Specification	Value
General Product Safety Regulation (GPSR) URL	https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true ; HP REG 23010, 08028 Barcelona, Spain ; reg@hp.com

Other features

Specification	Value
Supplied AC adapter type	Paint finish
