ASUS ProArt StudioBook 16 OLED H7600ZW-OLED-L751X Intel® Core™ i7 i7-12700H Laptop

ProArt StudioBook 16 OLED H7600ZW-OLED-L751X Intel® Core™ i7 i7-12700H Laptop

40.6 cm (16") WQUXGA 16 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 3070 Wi-Fi

Model H7600ZW-OLED-L751XPart no. 90NB0XJ1-M00190EAN 195553793117

117 specifications Checked today

Display40.6 cm (16")
Resolution3840 x 2400 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage2 TB
GraphicsNVIDIA GeForce RTX 3070

See all specifications

Overview

Display: 40.6 cm (16")
Resolution: 3840 x 2400 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 2 TB
Graphics: NVIDIA GeForce RTX 3070

Brand: ASUS
Category: Laptop
Model: H7600ZW-OLED-L751X
Part number: 90NB0XJ1-M00190
EAN / UPC: 195553793117, 4711081793113
Also known as: ASUS ProArt StudioBook 16 OLED H7600ZW-OLED-L751X Intel® Core™ i7 i7-12700H Laptop 40.6 cm (16") WQUXGA 16 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 3070 Wi-Fi

Specifications

117 specifications in 18 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black
Colour name	Mineral Black
Form factor	Clamshell
Housing material	Aluminium, Magnesium
Market positioning	Business

Display

Specification	Value
Display diagonal	40.6 cm (16")
Display resolution	3840 x 2400 pixels
Touchscreen	No
HD type	WQUXGA
Panel type	OLED
Native aspect ratio	16:10
Display surface	Gloss
Display brightness	550 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
Contrast ratio (typical)	1000000:1
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	HDR True Black 500

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	12th gen Intel® Core™ i7
Processor model	i7-12700H
Processor cores	14
Processor boost frequency	4.7 GHz
Processor cache	24 MB
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Maximum turbo power	115 W
Processor base power	45 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Memory form factor	SO-DIMM
Memory slots	2x SO-DIMM
Maximum internal memory	64 GB

Storage

Specification	Value
Total storage capacity	2 TB
Storage media	SSD
Total SSDs capacity	2 TB
Number of SSDs installed	2
SSD capacity	1 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	SD

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 3070
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics
On-board graphics card 4K support	Yes
On-board graphics card 6K support	Yes

Audio

Specification	Value
Audio system	Smart Amp
Speakers manufacturer	Harman Kardon
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,1000,100 Mbit/s
Bluetooth	Yes
Bluetooth version	5.2

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes

Performance

Specification	Value
Voice control	Yes

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Trial software	McAfee LiveSafe

Processor special features

Specification	Value
CPU configuration (max)	1
Embedded options available	No
Execute Disable Bit	Yes
Intel Flex Memory Access	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh

Power

Specification	Value
AC adapter power	240 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	12 A
AC adapter output voltage	20 V
DC-in jack	Yes
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Fingerprint reader	Yes
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Password protection	Yes
Password protection type	BIOS, HDD, User

Weight & dimensions

Specification	Value
Weight	2.4 kg
Width	362 mm
Depth	264 mm
Height	19.9 mm
