ASUS TUF Gaming A15 FA507UI-HQ026W-BE AMD Ryzen™ 9 8945H Laptop

TUF Gaming A15 FA507UI-HQ026W-BE AMD Ryzen™ 9 8945H Laptop

39.6 cm (15.6") Wide Quad HD 32 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 4070 Wi-Fi 6 (802.11ax

Model FA507UI-HQ026W-BEPart no. 90NR0I65-M007J0EAN 197105632400

113 specifications Checked today

Display39.6 cm (15.6")
Resolution2560 x 1440 pixels
ProcessorAMD Ryzen™ 9
Memory32 GB
Storage2 TB
GraphicsNVIDIA GeForce RTX 4070

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 2560 x 1440 pixels
Processor: AMD Ryzen™ 9
Memory: 32 GB
Storage: 2 TB
Graphics: NVIDIA GeForce RTX 4070

Brand: ASUS
Category: Laptop
Model: FA507UI-HQ026W-BE
Part number: 90NR0I65-M007J0
EAN / UPC: 197105632400, 4711387632406
Also known as: ASUS TUF Gaming A15 FA507UI-HQ026W-BE AMD Ryzen™ 9 8945H Laptop 39.6 cm (15.6") Wide Quad HD 32 GB DDR5-SDRAM 2 TB SSD NVIDIA GeForce RTX 4070 Wi-Fi 6 (802.11ax

Specifications

113 specifications in 19 groups

Design

Specification	Value
Product type	Laptop
Product colour	Black, Grey
Colour name	Mecha Gray
Form factor	Clamshell
Housing material	Plastic
Market positioning	Gaming

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	2560 x 1440 pixels
Touchscreen	No
HD type	Wide Quad HD
Native aspect ratio	16:9
Anti-glare screen	Yes
Display brightness	300 cd/m²
Colour gamut	100%
RGB colour space	DCI-P3
Maximum refresh rate	165 Hz
Contrast ratio (typical)	1000:1

Processor

Specification	Value
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 9
Processor generation	AMD Ryzen 8000 Series
Processor model	8945H
Processor cores	8
Processor boost frequency	5.2 GHz
Processor frequency	4 GHz
Processor cache	24 MB
Processor cache type	L2 & L3

Neural processor unit (NPU)

Specification	Value
Neural processor unit (NPU)	AMD Ryzen AI
Total processor performance up to	39 TOPs
NPU performance up to	16 TOPs

Memory

Specification	Value
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 16 GB
Memory slots	2x SO-DIMM
Maximum internal memory	32 GB
Memory channels	Dual-channel

Storage

Specification	Value
Total storage capacity	2 TB
Storage media	SSD
Total SSDs capacity	2 TB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
Optical drive type	No

Graphics

Specification	Value
On-board graphics card	Yes
Discrete graphics card	Yes
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA GeForce RTX 4070
Discrete graphics card memory	8 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	AMD
On-board graphics card model	AMD Radeon 780M
NVIDIA G-SYNC	Yes

Audio

Specification	Value
Audio system	Dolby Atmos
Number of built-in speakers	2
Built-in microphone	Yes

Camera

Specification	Value
Front camera	Yes
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels

Network

Specification	Value
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.3

Ports & interfaces

Specification	Value
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB4 Gen 3x2 ports quantity	1
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
Power adapter barrel connector	6.0 mm
USB Type-C DisplayPort Alternate Mode	Yes

Performance

Specification	Value
Repairability index	8.6

Keyboard

Specification	Value
Pointing device	Touchpad
Keyboard backlit	Yes
Numeric keypad	Yes
Keyboard backlit colour	RGB
Keyboard backlit zone	1-zone RGB
Keyboard layout	AZERTY
Keyboard language	Belgian

Software

Specification	Value
Operating system installed	Windows 11 Home
Operating system architecture	64-bit
Trial software	1-month trial for new Microsoft 365 customers. Credit card required. McAfee® 30 days free trial
Bundled software	Xbox Game Pass Ultimate_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Ultimate. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery capacity	90 Wh
Fast charging	Yes
Fast charging time (50%)	30 min

Power

Specification	Value
AC adapter power	240 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	12 A
AC adapter output voltage	20 V
USB Power Delivery (USB PD)	Yes

Security

Specification	Value
Cable lock slot	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection	Yes
Password protection type	BIOS, User

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Bronze
Sustainability compliance	Yes

Weight & dimensions

Specification	Value
Weight	2.2 kg
Width	354 mm
Depth	251 mm
Height (front)	2.24 cm
Height (rear)	2.49 cm
