Yealink T48S Skype for Business Edition
Model T48S Skype for Business EditionPart no. 1301073EAN 841885100689
79 specifications
- Display17.8 cm (7")
- Resolution800 x 480 pixels
- TypeIP Phone
- ColourBlack
- Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
- Common area phone (CAP)Yes
Overview
- Display
- 17.8 cm (7")
- Resolution
- 800 x 480 pixels
- Type
- IP Phone
- Colour
- Black
- Dual-Tone Multi-Frequency (DTMF) modes
- In-band, Out-of band, SIP info
- Common area phone (CAP)
- Yes
- Brand
- Yealink
- Category
- IP Phone
- Model
- T48S Skype for Business Edition
- Part number
- 1301073
- EAN / UPC
- 841885100689
- Also known as
- Yealink T48S Skype for Business Edition
Specifications
79 specifications in 15 groups
Design
| Specification | Value |
|---|---|
| Product type | IP Phone |
| Handset type | Wired handset |
| Product colour | Black |
| Device lock | Yes |
| Mounting | Desk/Wall |
| Wall mountable | Yes |
Performance
| Specification | Value |
|---|---|
| Dual-Tone Multi-Frequency (DTMF) modes | In-band, Out-of band, SIP info |
| Compatible products | Skype for Business |
Phone features
| Specification | Value |
|---|---|
| Common area phone (CAP) | Yes |
| Hot desking | Yes |
| Call forwarding | Yes |
| Call history | Yes |
| Call hold | Yes |
| Call park | Yes |
| Call pick up | Yes |
| Call transfer | Yes |
| Call waiting | Yes |
| Caller ID | Yes |
| Do not disturb function | Yes |
| Emergency call | Yes |
| Full duplex | Yes |
| Intercom | Yes |
| Message-waiting indicator (MWI) | Yes |
| Redialing | Yes |
Management features
| Specification | Value |
|---|---|
| Integrated voicemail | Yes |
| Volume control | Digital |
Display
| Specification | Value |
|---|---|
| Display diagonal | 17.8 cm (7") |
| Display resolution | 800 x 480 pixels |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| Backlight display | Yes |
| Graphical user interface (GUI) language | Multi |
Camera
| Specification | Value |
|---|---|
| Front camera | No |
Audio
| Specification | Value |
|---|---|
| Speakerphone | Yes |
| Microphone mute | Yes |
| Automatic gain control | Yes |
| Comfort noise generation (CNG) | Yes |
| Packet loss concealment (PLC) | Yes |
| Voice codecs | AGC, AJB, CNG, G.711alaw, G.711ulaw, G.722, G.723.1, G.726, G.729A, G.729B, PLC, Silk, VAD, iLBC |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Wi-Fi | No |
| Bluetooth | No |
| DHCP client | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Security algorithms | HTTPS, MD5, SRTP, TLS |
| Supported network protocols | SIP v1 (RFC2543), v2 (RFC3261), LLDP-MED VLAN, IPv4/IPv6, UDP/TCP/DNS-SRV (RFC 3263) |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion module support | Yes |
| RJ-9 ports quantity | 2 |
Certificates
| Specification | Value |
|---|---|
| Skype | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 5 V |
| AC adapter output current | 2 A |
| Power consumption (typical) | 4.9 W |
| Power consumption (Power over Ethernet (PoE)) | 7.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 95% |
| Storage temperature (T-T) | -10 - 50 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 266 mm |
| Depth | 226 mm |
| Height | 185 mm |
| Package width | 263 mm |
| Package depth | 324 mm |
| Package height | 128 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | LAN (RJ-45) |
| Handset | Yes |
| Number of handles included | 1 pc(s) |
| Quick start guide | Yes |
| Stand included | Yes |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case gross weight | 9 kg |
| Master (outer) case height | 338 mm |
| Master (outer) case length | 338 mm |
| Master (outer) case net weight | 8.2 kg |
| Master (outer) case width | 660 mm |
| Products per master (outer) case | 5 pc(s) |
