FireCuda 510
1 TB M.2 PCI Express 3.0 NVMe 3D TLC
Model 510Part no. ZP500GM3A021EAN 763649138236
37 specifications
- Storage1 TB
- ConnectivityPCI Express 3.0
- Weight8.1 g
- Power consumption (average)5.3 W
- Width22.1 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 1 TB
- Connectivity
- PCI Express 3.0
- Weight
- 8.1 g
- Power consumption (average)
- 5.3 W
- Width
- 22.1 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Seagate
- Category
- Internal Solid State Drive
- Model
- 510
- Part numbers
- ZP500GM3A021, ZP1000GM30011, ZP256CM30041, ZP1000GM3A011, ZP2000GM30021, ZP512CM30041 +16 more
- EAN / UPC
- 763649138236, 763649133989, 8719706016599, 763649134009 +28 more
- Also known as
- Seagate FireCuda 510 1 TB M.2 PCI Express 3.0 NVMe 3D TLC
Specifications
37 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 1 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | 3D TLC |
| Component for | PC |
| Hardware encryption | No |
| Read speed | 3450 MB/s |
| Write speed | 3200 MB/s |
| Random read (4KB) | 620000 IOPS |
| Random write (4KB) | 600000 IOPS |
| PCI Express interface data lanes | x4 |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Mean time between failures (MTBF) | 1800000 h |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8.1 |
| Linux operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (average) | 5.3 W |
| Power consumption (idle) | 0.02 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22.1 mm |
| Depth | 80.2 mm |
| Height | 3.58 mm |
| Weight | 8.1 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 109 mm |
| Package depth | 134.2 mm |
| Package height | 24 mm |
| Package weight | 62 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 278 mm |
| Master (outer) case length | 129 mm |
| Master (outer) case height | 169 mm |
| Master (outer) case net weight | 920 g |
| Products per master (outer) case | 10 pc(s) |
