ST6000NM0255 internal hard drive
6 TB 7200 RPM 256 MB 3.5" SAS
Model ST6000NM0255EAN 763649090572
30 specifications
- Storage6 TB
- ConnectivitySAS
- TypeHDD
- Weight705 g
- Power consumption (typical)9.2 W
- Operating temperature (T-T)5 - 60 °C
Overview
- Storage
- 6 TB
- Connectivity
- SAS
- Type
- HDD
- Weight
- 705 g
- Power consumption (typical)
- 9.2 W
- Operating temperature (T-T)
- 5 - 60 °C
- Brand
- Seagate
- Category
- Internal Hard Drive
- Model
- ST6000NM0255
- Part number
- ST6000NM0255
- EAN / UPC
- 763649090572, 763649101063, 7636490077890
- Also known as
- Seagate ST6000NM0255 internal hard drive 6 TB 7200 RPM 256 MB 3.5" SAS
Specifications
30 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 6 TB |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Interface | SAS |
| Type | HDD |
| Component for | Server/workstation |
| Storage drive buffer size | 256 MB |
| HDD interface transfer rate | 12 Gbit/s |
| Average latency | 4.16 ms |
| SMART technology | Yes |
| Bytes per sector | 4224 |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 9.2 W |
| Power consumption (idle) | 8.37 W |
| Operating voltage | 5 / 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating vibration | 5 G |
| Operating altitude | -304.8 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
Packaging content
| Specification | Value |
|---|---|
| Storage drive adapter included | No |
Technical details
| Specification | Value |
|---|---|
| Doesn't contain | Halogen |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 101.8 mm |
| Depth | 147 mm |
| Height | 26.1 mm |
| Weight | 705 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
