Seagate U-series ST320014A-RFB internal hard drive

Seagate U-series ST320014A-RFB internal hard drive

20 GB 5400 RPM 2 MB 3.5" Ultra-ATA/100

Model ST320014A-RFBEAN 5705965691465

38 specifications
  • Storage20 GB
  • ConnectivityUltra-ATA/100
  • TypeHDD
  • Weight455 g
  • Power consumption (typical)6 W
  • Operating temperature (T-T)0 - 60 °C
See all specifications

Overview

Storage
20 GB
Connectivity
Ultra-ATA/100
Type
HDD
Weight
455 g
Power consumption (typical)
6 W
Operating temperature (T-T)
0 - 60 °C
Brand
Seagate
Model
ST320014A-RFB
Part number
ST320014A-RFB
EAN / UPC
5705965691465
Also known as
Seagate U-series ST320014A-RFB internal hard drive 20 GB 5400 RPM 2 MB 3.5" Ultra-ATA/100

Specifications

38 specifications in 6 groups

Features

HDD capacity20 GB
HDD speed5400 RPM
HDD size3.5"
InterfaceUltra-ATA/100
TypeHDD
Storage drive buffer size2 MB
HDD number of heads1
Read seek time18 ms
Write seek time24.9 ms
Full stroke seek time42 ms
Track to track seek time1.2 ms
Average seek time12.7 ms
SMART technologyYes
Bytes per sector512
Start/stop cycles50000
Mean time between failures (MTBF)600000 h

Power

Power consumption (typical)6 W
Power consumption (standby)1.2 W
Power consumption (idle)4.5 W
Power consumption (read)5.5 W
Power consumption (write)5.5 W
Operating voltage5 / 12 V

Operational conditions

Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%
Operating vibration0.5 G
Non-operating vibration5 G
Operating altitude-60.96 - 3048 m
Non-operating altitude-121.92 - 12192 m
Operating shock63 G
Non-operating shock350 G

Weight & dimensions

Width101.9 mm
Depth147 mm
Height20 mm
Weight455 g

Logistics data

Harmonized System (HS) code84717050

Other features

Drive ready time7 s
