SkyHawk AI 20 TB
Model SkyHawk AI 20 TBPart no. ST20000VE002EAN 763649169926
29 specifications
- Storage20 TB
- ConnectivitySerial ATA III
- TypeHDD
- Weight680 g
- Power consumption (typical)7.72 W
- Operating temperature (T-T)0 - 65 °C
Overview
- Storage
- 20 TB
- Connectivity
- Serial ATA III
- Type
- HDD
- Weight
- 680 g
- Power consumption (typical)
- 7.72 W
- Operating temperature (T-T)
- 0 - 65 °C
- Brand
- Seagate
- Category
- Internal Hard Drive
- Model
- SkyHawk AI 20 TB
- Part number
- ST20000VE002
- EAN / UPC
- 763649169926, 3807000010186, 5715063365335, 8719706427579
- Also known as
- Seagate SkyHawk AI 20 TB internal hard drive 7200 RPM 256 MB 3.5" Serial ATA III
Specifications
29 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 20 TB |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Interface | Serial ATA III |
| Type | HDD |
| Component for | Surveillance system |
| Storage drive buffer size | 256 MB |
| HDD interface transfer rate | 6 Gbit/s |
| HDD sustained transfer rate | 260 MiB/s |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| Rotational Vibration (RV) sensors | Yes |
| Number of AI channels | 32 |
| Start/stop cycles | 600000 |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 7.72 W |
| Power consumption (standby) | 1 W |
| Power consumption (idle) | 3.5 W |
| Operating voltage | 5 / 12 V |
| Start-up current | 2 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 65 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 101.8 mm |
| Depth | 147 mm |
| Height | 26.1 mm |
| Weight | 680 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717050 |
| Products per pallet layer | 8 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Products per master (outer) case | 20 pc(s) |
Other features
| Specification | Value |
|---|---|
| Maximum number of cameras supported | 64 |
