Seagate 80GB LD25.2
Model 80GB LD25.2Part no. ST980210AEAN 102646017296
26 specifications
- Storage80 GB
- ConnectivityIDE/ATA
- Weight100 g
- Operating voltage5 V
- Operating temperature (T-T)0 - 60 °C
- Width70.1 mm
Overview
- Storage
- 80 GB
- Connectivity
- IDE/ATA
- Weight
- 100 g
- Operating voltage
- 5 V
- Operating temperature (T-T)
- 0 - 60 °C
- Width
- 70.1 mm
- Brand
- Seagate
- Category
- Internal Hard Drive
- Model
- 80GB LD25.2
- Part number
- ST980210A
- EAN / UPC
- 102646017296, 683728151621, 4051154120416, 4250897400025
- Also known as
- Seagate LD25.2 80GB internal hard drive 5400 RPM 2 MB 2.5" IDE/ATA
Specifications
26 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 80 GB |
| HDD speed | 5400 RPM |
| HDD size | 2.5" |
| Interface | IDE/ATA |
| Storage drive buffer size | 2 MB |
| HDD number of heads | 2 |
| Average latency | 5.6 ms |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| Start-up current | 1.1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating shock | 175 G |
| Non-operating shock | 500 G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70.1 mm |
| Depth | 100.5 mm |
| Height | 9.7 mm |
| Weight | 100 g |
Other features
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Fibre Channel | No |
| FireWire 400 | No |
| FireWire 800 | No |
| Internal | Yes |
| Plug and Play | No |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 0 |
| USB powered | No |
