Origin Storage HDD 500GB 3.5in NearLine SATA 7200RPM
Model SA-500/7-NLEAN 5055146560197
38 specifications
- Storage500 GB
- ConnectivityNL-SATA
- TypeHDD
- Weight750 g
- Power consumption (idle)4.45 W
- Operating temperature (T-T)5 - 55 °C
Overview
- Storage
- 500 GB
- Connectivity
- NL-SATA
- Type
- HDD
- Weight
- 750 g
- Power consumption (idle)
- 4.45 W
- Operating temperature (T-T)
- 5 - 55 °C
- Brand
- Origin Storage
- Category
- Internal Hard Drive
- Model
- SA-500/7-NL
- Part number
- SA-500/7-NL
- EAN / UPC
- 5055146560197
- Also known as
- Origin Storage HDD 500GB 3.5in NearLine SATA 7200RPM
Specifications
38 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 500 GB |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Interface | NL-SATA |
| Type | HDD |
| Component for | Server/workstation |
| Hot-swap | No |
| Storage drive buffer size | 128 MB |
| HDD interface transfer rate | 6 Gbit/s |
| HDD number of heads | 3 |
| Average latency | 4.16 ms |
| 24/7 operation | No |
| Bytes per sector | 512 |
| Refurbished | No |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (idle) | 4.45 W |
| Power consumption (read) | 8.08 W |
| Operating voltage | 5 / 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating vibration | 0.25 G |
| Non-operating vibration | 4.9 G |
| Operating altitude | -304.8 - 3048 m |
| Non-operating altitude | -304.8 - 12192 m |
| Operating shock | 70 G |
| Non-operating shock | 300 G |
Packaging content
| Specification | Value |
|---|---|
| Storage drive adapter included | No |
| Storage drive caddy included | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 101.8 mm |
| Depth | 26.1 mm |
| Height | 147 mm |
| Weight | 750 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717050 |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Drive ready time | 20 s |
| Warranty period | 5 year(s) |
