Fujitsu 73.5GB, 3.5", 15K
Model 73.5GB, 3.5", 15KPart no. MBA3073NCEAN 5704327583974
29 specifications
- Storage73.5 GB
- ConnectivitySAS
- TypeHDD
- Weight800 g
- Power consumption (typical)12.4 W
- Operating temperature (T-T)5 - 55 °C
Overview
- Storage
- 73.5 GB
- Connectivity
- SAS
- Type
- HDD
- Weight
- 800 g
- Power consumption (typical)
- 12.4 W
- Operating temperature (T-T)
- 5 - 55 °C
- Brand
- Fujitsu
- Category
- Internal Hard Drive
- Model
- 73.5GB, 3.5", 15K
- Part numbers
- MBA3073NC, MBA3073NP
- EAN / UPC
- 5704327583974, 102646159002, 5032140000188, 5052178968724 +2 more
- Also known as
- Fujitsu 73.5GB, 3.5", 15K internal hard drive 15000 RPM 8 MB 3.5" SAS
Specifications
29 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 73.5 GB |
| HDD speed | 15000 RPM |
| HDD size | 3.5" |
| Interface | SAS |
| Type | HDD |
| Component for | Server/workstation |
| Storage drive buffer size | 8 MB |
| HDD number of cylinders | 1 |
| HDD number of heads | 2 |
| Track to track seek time | 0.2 ms |
| Average latency | 2 ms |
| Mean time between failures (MTBF) | 1400000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 12.4 W |
| Operating voltage | 5 / 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating vibration | 0.6 G |
| Non-operating vibration | 3.1 G |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Operating shock | 65 G |
| Non-operating shock | 250 G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 101.6 mm |
| Depth | 146 mm |
| Height | 24.4 mm |
| Weight | 800 g |
Other features
| Specification | Value |
|---|---|
| Drive ready time | 30 s |
