VC080 EDID emulator
Model VC080
23 specifications
- Weight150 g
- ColourBlack
- Maximum video resolution1920 x 1080 pixels
- Video port typeHDMI
- AC adapter output voltage5 V
- Width71.6 mm
Overview
- Weight
- 150 g
- Colour
- Black
- Maximum video resolution
- 1920 x 1080 pixels
- Video port type
- HDMI
- AC adapter output voltage
- 5 V
- Width
- 71.6 mm
- Brand
- ATEN
- Category
- EDID Emulator
- Model
- VC080
- Part number
- VC080
- Also known as
- ATEN VC080 EDID emulator
Specifications
23 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Video resolutions | 640 x 480,1280 x 720,1920 x 1080,1920 x 1200 |
| Bandwidth | 2.25 Gbit/s |
| Deep colour support | Yes |
| Consumer Electronics Control (CEC) support | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| Number of video inputs | 1 |
| Number of video outputs | 1 |
| HDCP | Yes |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| AC adapter output voltage | 5 V |
| Power consumption (max) | 0.15 W |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71.6 mm |
| Depth | 79 mm |
| Height | 24.5 mm |
| Weight | 150 g |
