DL7600 Pro
Model DL7600 ProPart no. S26391-F1051-L406EAN 4057185513487
33 specifications
- Weight22 kg
- ColourNo
- Paper feedPush tractor
- Product colourWhite
- Standard interfacesParallel, USB 1.1
- Print head24-pin
Overview
- Weight
- 22 kg
- Colour
- No
- Paper feed
- Push tractor
- Product colour
- White
- Standard interfaces
- Parallel, USB 1.1
- Print head
- 24-pin
- Brand
- Fujitsu
- Category
- Dot Matrix Printer
- Model
- DL7600 Pro
- Part number
- S26391-F1051-L406
- EAN / UPC
- 4057185513487
- Also known as
- Fujitsu DL7600 Pro dot matrix printer 360 x 360 DPI 864 cps
Specifications
33 specifications in 8 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Maximum resolution | 360 x 360 DPI |
| Maximum printing width (columns) | 136 |
| Maximum print speed | 864 cps |
| Maximum print speed (draft) | 864 cps |
| Maximum print speed (LQ) | 216 cps |
| Normal print speed | 432 cps |
| Maximum number of copies | 8 copies |
| Character sets | 852, 863, 866, ISO Latin 1, Italic |
Paper handling
| Specification | Value |
|---|---|
| Paper feed | Push tractor |
| Paper tray media types | Plain paper |
| Cut sheet width range | 55 - 420 mm |
| Cut sheet length range | 70 - 297 mm |
| Continuous paper width range | 102 - 420 mm |
Features
| Specification | Value |
|---|---|
| Product colour | White |
| Buffer size | 128 KB |
| Sound pressure level (printing) | 56 dB |
| Page description languages | ESC P |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Parallel, USB 1.1 |
| Cabling technology | 10/100Base-T(X) |
| Optional connectivity | Ethernet |
Endurance
| Specification | Value |
|---|---|
| Print head | 24-pin |
| Ribbon life | 18 million characters |
| Mean time between failures (MTBF) | 20000 h |
Power
| Specification | Value |
|---|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (standby) | 10 W |
| Power consumption (typical) | 275 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 38 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 600 mm |
| Depth | 350 mm |
| Height | 290 mm |
| Weight | 22 kg |
