TM-H5000II (012): Serial, w/o PS, ECW
Model TM-H5000IIPart no. C31C246012B1EAN 8715946670348
36 specifications
- ConnectivityWired
- Weight6.5 kg
- ColourNo
- Product colourWhite
- Print head9-pin
- Operating temperature (T-T)5 - 45 °C
Overview
- Connectivity
- Wired
- Weight
- 6.5 kg
- Colour
- No
- Product colour
- White
- Print head
- 9-pin
- Operating temperature (T-T)
- 5 - 45 °C
- Brand
- Epson
- Category
- Dot Matrix Printer
- Model
- TM-H5000II
- Part numbers
- C31C246012B1, C31C246012
- EAN / UPC
- 8715946670348, 3609740144110, 4058154268018, 5052883403978 +5 more
- Also known as
- Epson TM-H5000II (012): Serial, w/o PS, ECW
Specifications
36 specifications in 8 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Maximum resolution | 180 x 180 DPI |
| Maximum print speed | 311 cps |
| Normal print speed | 233 cps |
| Character density | 20 cpi |
| Maximum number of copies | 4 copies |
Features
| Specification | Value |
|---|---|
| Product colour | White |
| Buffer size | 4 KB |
| Country of origin | China |
Endurance
| Specification | Value |
|---|---|
| Print head | 9-pin |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 45 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 252 mm |
| Depth | 351 mm |
| Height | 201 mm |
| Weight | 6.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 332 mm |
| Package depth | 407 mm |
| Package height | 285 mm |
| Package weight | 7.4 kg |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 252 x 331 x 200 mm |
| Connectivity technology | Wired |
| Power requirements | 24 VDC + 10% |
| Box contents | Main unit, Power switch cover, Ribbon cartridge (slip), Thermal roll paper, User manual |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Pallet gross height | 100 cm |
| Pallet gross width | 120 cm |
| Pallet height (UK) | 186 cm |
| Pallet length (UK) | 120 cm |
| Products per pallet | 24 pc(s) |
| Products per pallet (UK) | 36 pc(s) |
| Products per pallet layer | 4 pc(s) |
| Products per pallet layer (UK) | 6 pc(s) |
