DFX-9000
Model DFX-9000Part no. C12C800381EAN 103438001134
50 specifications
- ConnectivityWired
- Weight34 kg
- ColourNo
- Maximum print sizeA4 (210 x 297 mm)
- Buffer size128 KB
- Standard interfacesParallel, RS-232, USB 2.0
Overview
- Connectivity
- Wired
- Weight
- 34 kg
- Colour
- No
- Maximum print size
- A4 (210 x 297 mm)
- Buffer size
- 128 KB
- Standard interfaces
- Parallel, RS-232, USB 2.0
- Brand
- Epson
- Category
- Dot Matrix Printer
- Model
- DFX-9000
- Part numbers
- C12C800381, C11C605011BZ, C11C605011DA, C11C605001, C11C605021
- EAN / UPC
- 103438001134, 4053162314184, 4054842137222, 8715946275987 +10 more
- Also known as
- Epson DFX-9000
Specifications
50 specifications in 12 groups
Printing
| Specification | Value |
|---|---|
| Colour | No |
| Maximum resolution | 240 x 144 DPI |
| Maximum printing width (columns) | 136 |
| Maximum print speed | 1550 cps |
| Maximum print speed (draft) | 1320 cps |
| Maximum print speed (LQ) | 330 cps |
| Character pitch | 10,12 cpi |
| Maximum number of copies | 10 copies |
| Built-in barcodes | Code 39, POSTNET, UPC-A, UPC-E |
Paper handling
| Specification | Value |
|---|---|
| Maximum print size | A4 (210 x 297 mm) |
| Paper tray media types | Labels |
Features
| Specification | Value |
|---|---|
| Buffer size | 128 KB |
| Sound pressure level (printing) | 58 dB |
| Page description languages | ESC P, PPDS |
| Country of origin | Japan |
Ports & interfaces
| Specification | Value |
|---|---|
| Standard interfaces | Parallel, RS-232, USB 2.0 |
| Optional connectivity | Ethernet |
Endurance
| Specification | Value |
|---|---|
| Print head | 9-pin |
| Print direction | Bidirectional |
| Print head life | 200 million characters |
| Ribbon life (black, draft) | 15 million characters |
| Mean time between failures (MTBF) | 20000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 75 W |
| Power consumption (typical) | 185 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 10 - 80% |
System requirements
| Specification | Value |
|---|---|
| Bundled software | Epson Status Monitor |
| Windows operating systems supported | Windows 2000, Windows 7, Windows 8, Windows 98, Windows XP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 700 mm |
| Depth | 378 mm |
| Height | 363 mm |
| Weight | 34 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 485 mm |
| Package depth | 840 mm |
| Package height | 505 mm |
| Package weight | 35.5 g |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Print technology | Dot matrix |
| Needles | 36 (4 x 9) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84433210 |
| Pallet gross height | 100 cm |
| Pallet gross width | 120 cm |
| Pallet height (UK) | 2.1 m |
| Pallet length (UK) | 120 cm |
| Pallet width (UK) | 100 cm |
| Products per pallet | 4 pc(s) |
| Products per pallet (UK) | 8 pc(s) |
| Products per pallet layer | 1 pc(s) |
| Products per pallet layer (UK) | 2 pc(s) |
