ABPC-543 (PoE)
Model ABPC-543 (PoE)Part no. 99108610.455
49 specifications
- ProcessorRockchip RK3288
- Memory2048 MB
- Storage8 GB
- OSAndroid
- Weight470 g
- ColourBlack
Overview
- Processor
- Rockchip RK3288
- Memory
- 2048 MB
- Storage
- 8 GB
- OS
- Android
- Weight
- 470 g
- Colour
- Black
- Brand
- ProDVX
- Category
- Digital Media Player
- Model
- ABPC-543 (PoE)
- Part number
- 99108610.455
- Also known as
- ProDVX ABPC-543P
Specifications
49 specifications in 15 groups
Features
| Specification | Value |
|---|---|
| Product colour | Black |
| Certification | FCC, CE, RoHS |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Rockchip |
| Processor model | Rockchip RK3288 |
| Processor architecture | Cortex-A17 |
| Processor frequency | 1600 MHz |
| Processor cores | 4 |
Storage
| Specification | Value |
|---|---|
| Built-in storage media | Yes |
| Storage media type | Flash |
| Total storage capacity | 8 GB |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2048 MB |
| Internal memory type | DDR3 |
Graphics
| Specification | Value |
|---|---|
| Graphics card | Mali-T764 |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 4 |
| Audio (L/R) out | 1 |
| DC-in jack | Yes |
| Number of HDMI outputs | 1 |
| S/PDIF out port | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000,100 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Networking standards | IEEE 802.3at |
Software
| Specification | Value |
|---|---|
| Operating system installed | Android |
| Operating system version | 5.1 |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 9 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 155 mm |
| Depth | 31 mm |
| Height | 130 mm |
| Weight | 470 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), CE, RoHS |
Other features
| Specification | Value |
|---|---|
| Battery type | Lithium‐metal non‐rechargeable coin |
| Internal memory | 2 GB |
| Mean time between failures (MTBF) | 45000 h |
| RS-232 ports | 2 |
