Wireless HD Media Player
Model Wireless HD Media PlayerPart no. DSM-520EAN 790069283451
25 specifications
- ConnectivityUSB 2.0, Ethernet, Wi-Fi
- Weight2.5 kg
- Image formats supportedBMP, GIF, PNG
- Impedance50 Ω
- HDMI ports quantity1
- Antenna gain level (max)2 dBi
Overview
- Connectivity
- USB 2.0, Ethernet, Wi-Fi
- Weight
- 2.5 kg
- Image formats supported
- BMP, GIF, PNG
- Impedance
- 50 Ω
- HDMI ports quantity
- 1
- Antenna gain level (max)
- 2 dBi
- Brand
- D-Link
- Category
- Digital Media Player
- Model
- Wireless HD Media Player
- Part number
- DSM-520
- EAN / UPC
- 790069283451, 790069288197
- Also known as
- D-Link Wireless HD Media Player
Specifications
25 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| Image formats supported | BMP, GIF, PNG |
| Video compression formats | AVI, MPEG1, MPEG2, MPEG4, Xvid |
| Subtitle formats supported | SRT |
| Audio formats supported | AIFF, MP3, WAV, WMA |
| Certification | FCC, CSA, CE |
Audio
| Specification | Value |
|---|---|
| Impedance | 50 Ω |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| Interface | USB 2.0, Ethernet, Wi-Fi |
Network
| Specification | Value |
|---|---|
| Antenna gain level (max) | 2 dBi |
| Networking features | Fast Ethernet, Wireless LAN |
| Security algorithms | WPA-PSK |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 10 W |
| Power requirements | 100 - 240V, 50/60Hz, 0.5A |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.5 kg |
| Dimensions (WxDxH) | 286 x 425 x 38 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 55 °C |
| Operating relative humidity (H-H) | 10 - 95% |
Other features
| Specification | Value |
|---|---|
| Antenna type | External |
| Compliance industry standards | IEEE 802.11g, IEEE 802.11b |
| Data transfer rate | 480 Mbit/s |
| Supported data transfer rates | WLAN: 54 Mbps |
| Supported protocols | TCP/IP, UPnP AV 1.0, DHCP |
| Connectivity technology | Wireless |
| I/O ports | Coax digital audio Optical digital audio Composite audio & video S-video SCART USB Ethernet 10/100 (RJ-45) |
