NEC Intel Xeon E5606
Model Intel Xeon E5606Part no. N8101-494-O
26 specifications Checked 3 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- Maximum internal memory supported by processor288 GB
- Market segmentServer
- Package dimensions (WxDxH)42.5 x 42.5 x 45 mm
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Maximum internal memory supported by processor
- 288 GB
- Market segment
- Server
- Package dimensions (WxDxH)
- 42.5 x 42.5 x 45 mm
- Brand
- NEC
- Category
- CPU
- Model
- Intel Xeon E5606
- Part numbers
- N8101-494-O, N8101-484F-O, CPU-5606-EI-01, N8101-489F-O
- Also known as
- NEC Intel Xeon E5606 processor 2.13 GHz 8 MB L3
Specifications
26 specifications in 5 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | E5606 |
| Processor base frequency | 2.13 GHz |
| Processor cores | 4 |
| Processor socket | Socket B (LGA 1366) |
| Processor lithography | 32 nm |
| Component for | Server/workstation |
| Processor threads | 4 |
| System bus rate | 4.8 GT/s |
| Processor operating modes | 64-bit |
| Processor cache | 8 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 80 W |
| VID Voltage Range | 0.750 - 1.350 V |
| Stepping | B1 |
| CPU multiplier (bus/core ratio) | 16 |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| Processor system type | DP |
| Processor code | SLC2N |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 288 GB |
| Memory clock speeds supported by processor | 800,1066 MHz |
| Memory channels | Triple-channel |
| ECC | Yes |
Features
| Specification | Value |
|---|---|
| Market segment | Server |
Weight & dimensions
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 42.5 x 42.5 x 45 mm |
Other features
| Specification | Value |
|---|---|
| On-board memory controller | Yes |
