Intel Core i5-6300U
Model Intel Core i5-6300UPart no. S26391-F1501-E630
135 specifications Checked today
- ProcessorIntel® Core™ i5
- GraphicsNot available
- TypeSystem on Chip
- Maximum internal memory supported by processor32 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Core™ i5
- Graphics
- Not available
- Type
- System on Chip
- Maximum internal memory supported by processor
- 32 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Core i5-6300U
- Part number
- S26391-F1501-E630
- Also known as
- Fujitsu Core Intel i5-6300U processor 2.4 GHz 3 MB Smart Cache
Specifications
135 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | 6th gen Intel® Core™ i5 |
| Processor model | i5-6300U |
| Processor base frequency | 2.4 GHz |
| Processor cores | 2 |
| Processor socket | LGA 1356 (Socket B2) |
| Processor lithography | 14 nm |
| Component for | Laptop |
| Processor series | Intel® Core™ i5-6300 Mobile Series |
| Processor threads | 4 |
| System bus rate | 4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3 GHz |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 15 W |
| Configurable TDP-up frequency | 2.5 GHz |
| Configurable TDP-up | 25 W |
| Configurable TDP-down frequency | 0.8 GHz |
| Configurable TDP-down | 7.5 W |
| Stepping | D1 |
| Bus type | QPI |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| Processor codename | Skylake |
| Processor code | SR2F0 |
| Processor ARK ID | 88190 |
| Generation | 6th Generation |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM |
| Memory clock speeds supported by processor | 1866,2133,1600 MHz |
| Memory channels | Dual-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics 520 |
| Maximum on-board graphics card memory | 1.74 GB |
| On-board graphics card outputs supported | DVI, Embedded DisplayPort (eDP), DisplayPort, HDMI |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1000 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card 4K support | Yes |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 24 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card ID | 1916 |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Mobile |
| Maximum number of PCI Express lanes | 12 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x4, 4x1 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
| Graphics & IMC lithography | 14 nm |
| PCI Express CEM revision | 3.0 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Smart Response Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | 1 |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 100 °C |
Technical details
| Specification | Value |
|---|---|
| Maximum graphics card memory | 1740 MB |
| Maximum graphics card memory | 32 GB |
| Processor cache | 3072 KB |
| Product type | System on Chip |
| Video compression formats | Yes |
| Born on date | Q3'15 |
| Bus bandwidth | 4 |
| Bus speed | 4 GT/s |
| Bus type units | GT/s |
| Graphics max dynamic frequency | 1.00 GHz |
| Last change | 63903513 |
| Launch date | Q3'15 |
| Maximum memory | 32 GB |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2304@24Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (VGA) | N/A |
| Maximum resolution (WiDi) | 1080p |
| OpenGL support | Yes |
| Processor ID | 0x1916 |
| Processor brand name | Intel Core i5 Intel Core i5 Processor |
| Product family | 6th Generation Intel Core i5 Processors |
| Product name | Intel Core i5-6300U (3M Cache, up to 3.00 GHz) |
| Status | Launched |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 42 X 24 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Cache memory | 3 MB |
| L2 cache | 3072 KB |
| Maximum internal memory | 32 GB |
| Maximum internal memory | 32768 MB |
| Supported processor frequency (max) | 3000 GHz |
| Video decoding | Yes |
| Graphics output | eDP/DP/HDMI/DVI |
